High Absorption Flat Plate Solar Thermal Collector Ultrasonic Welding

High Absorption Flat Plate Solar Thermal Collector Ultrasonic Welding

    • High Absorption Flat Plate Solar Thermal Collector Ultrasonic Welding
    • High Absorption Flat Plate Solar Thermal Collector Ultrasonic Welding
  • High Absorption Flat Plate Solar Thermal Collector Ultrasonic Welding

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 2 sqm

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Back Plate: Galvanized Steel Collector: Flat Plate
    Frame: Stainless Steel Cover Material: Tempered Textured Glass
    Absorber Material: Aluminum Full Plate Absorber Coating: Blue Titanium
    Welding: Ultrasonic Welding Header Pipe: Red Copper
    High Light:

    photovoltaic thermal hybrid solar collector

    ,

    solar thermal flat plate collectors

    High Absorption Blue Titanium Copper Project Flat Plate Thermal Solar Collector Stainless Steel Frame



    Specifications



    Flat Plate Solar Collector

    easy installation and high efficiency

    suitable for domestic

    industrial and commercial heating use



    Features description



    Flat plate solar collector is a device that absorbs solar energy from the sun and converts it into usable heat energy, the heat is normally absorbed by water in the loop, or a freeze-resistant water mixture, a kind of medium used to supplement hot water heating or house air heating.



    1. Suitable for domestic, dormitories, parks, hotels, schools, public showers, swimming pools, restaurants and other sites requiring for large hot water use

    2. The panel is of high efficiency and good performance

    3. Suitable for open or closed Loop (glycol-water)

    4. Suggest this type of solar collector for warm areas, for extremely cold areas, use anti-freezing liquid for circulation

    5. Easy installation on slope or flat roof with little maintenance needed

    6. Suggest 2 square meters collector area of this panel to match 100L water tank.



    Flat Plate Solar Collector Technical Parameters



    Specifications Dimension(mm) 2000*1060*70mm / 2000*1060*80mm / 2000*1060*90
    Aperture area 2 m2
    Net Weight 31kg / 32kg / 34kg accordingly
    Cover Sheet Glass Material Float /tempered / tempered woven / low-iron tempered woven glass
    Thickness Low-iron tempered woven 3.2mm, other three 4mm
    Transmission 87%~91%
    Absorber Core Material Copper & aluminum
    Coating Anodizing
    Efficiency Absorptivity ≥95%, emissivity ≤20%
    Absorber Plate Copper & aluminum, δ=0.45mm
    Header Tube All copper T2, Φ25*0.6*1060mm, 2pcs
    Riser Tube Copper & aluminum, Φ14*0.45mm, 7pcs
    Jointing Composite technology
    Insulation Materials Glass wool+ benzene plate/glass wool+ high dense polyurethane foam
    Thickness 30mm / 40mm / 50mm thickness accordingly
    Casing Material Zincification plate 0.3mm / embossed aluminum back sheet 0.3mm
    Sealing Metal elasticity proof, anti-aging seal
    Working Pressure 3 bar
    Work Temperature (-)35~180C



    Why choose us?



    1. Complete International Certificates: CE, Solar KEYMARK, TUV, SRCC, SGS, ISO, FSEC, ONNCCE, GMC, ALIBABA etc.

    2. The first grade product quality: All passed EN12975(12976)-1,2, the heat efficiency of Solar Keymark certificate is 0.73209 in the top of China. Very rarely factory can pass EN12976 in China.

    3. We are full export experience 10 years, over 60 countries in the world.

    4. Own the best group of R&D, the best quality and the best service for customers.

    5. OEM/ODM is available.



    Our Service:

    Professional manufacturer.

    Inquiry response: Your inquiries will be replied in 24 hours.

    Sample support: Samples are available in 5-7days.

    Delivery time: Your shipment will be loaded in 10-15days, depends on quantity.

    Payment term: T/T

    OEM is welcome.



    After-Sale Service:

    All Products will have been strictly Quality Checked before packing

    All Products will be well packed before shipping

    All our products have 3 year warranty.



    Notice:

    1. The angle of the frame can be changed in the production as the virtual geographical condition of the customers.

    2. We can design the suitable angle for the customers.

    3. We offer the spare accessories and tubes for your order for free.

    4. We can offer the different material of water tank , frame , and tubes according to your request.
