No Leakage Thermal Solar Collector Natural Circulation Easy Installation

No Leakage Thermal Solar Collector Natural Circulation Easy Installation

    • No Leakage Thermal Solar Collector Natural Circulation Easy Installation
    • No Leakage Thermal Solar Collector Natural Circulation Easy Installation
  • No Leakage Thermal Solar Collector Natural Circulation Easy Installation

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 2 sqm

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Circulation: Natural Circulation Dimension Of End Pipe: φ22 ×δ0.6mm
    Colletor: Flat Plate Header Material: Copper TP2
    Frame: Aluminum Alloy Gross Area (m2): 2
    Absorber Coating: Anode Oxidation Frame Colour: Silver
    High Light:

    solar thermal collectors


    solar thermal flat plate collectors

    No Leakage Natural Circulation Flat Plate Thermal Solar Collector High Efficiency


    Titanium coating advantages


    1. Titanium coating is evenly distributed and high quality.

    2. High Thermal efficiency, 95% absorption, 6% emission.

    3. Excellent weather resistance, fastness for 25 years, efficiency declines less than 5%.




    Application for Flat Plate Solar Collector

    Flat plate solar thermal collector is suitable for residential or commercial solar water heating projects, such as hot water for real estates, hotels, factories, hospitals, schools, swimming pools, space or floor heating, etc.


    Features of Flat Plate Solar Collector

    1. Most wide-used and practical collector in solar water heating system;

    2. Wide applications for water heating, pool heating, space heating;

    3. Large solar heating capacity up to 500,000 Liter hot water;

    4. Much safe and stable performance with little maintenance;

    5. Very efficient direct or indirect solar water heating;

    6. Strong adaptability to flat or slope roof installation;

    7. Easy installation and connection with simple structure;

    8. Super anti-freezing performance with glycol-water mixture;

    9. Applicable to passive and active solar water heating system;

    10. 10 years project installation experience for consultation.


    Model A-2000/1000/80 B-2000/1000/80 C-2000/1000/80 D-2000/1000/80
    Coating Anode Oxidation Black chrome Black chrome Blue coating
    Welding Laser Ultrasonic Laser Laser
    Material of Absorber Copper & Aluminum Copper Copper & Aluminum Copper & Aluminum

    Size & Quantity

    header pipe

    22*08mm 2PCS

    Size &Quantity

    branch pipe

    10*0.6mm 7PCS
    Absorption rate 0.90±0.03 0.93±0.03 0.92±0.03 0.94±0.02
    Reflection rate 0.18±0.05 0.10±0.05 0.10±0.05 0.05±0.02
    Collector size 2000 x 1000 x 80mm
    Frame color Silver/Black/Champagne
    Gross area 2m2
    Absorber area 1.85m2
    Sealing EPDM
    cover material Ultra white and low iron fabric surface tempered glass
    Cover transmission 92%
    Back plate material 0.30mm galvanized steel
    Insulation 30mm glass wool
    Max working pressure 0.6MPa
    weight 37kg 37kg 38kg 38kg


    Packaging & Shipping


    Packaging Details: Export strong corrugated carton.

    Delivery Detail: Within 7 - 10 days for container order quantity upon confirmed invoice or sales contract.



    10 years international responsibility for Flat Plate Panel Solar Collector due to original quality problems.


    Basic trade term & packages


    MOQ: 20'GP container (Sample is available)
    Warranty: 10 years guarantee for whole set solar water heater
    Payment term: 30% deposit by TT, Balance for BL by TT or LC
    Delivery time: 7-15 days after confirmed
    Port of departure: Shanghai or Ningbo
    Supply ability: 8000 sets per month
    Package: Standard export cartons


    Quality Guarantee


    We provide 5years warranty of products and shipment with 1% spare parts


    We can send the parts free on condition that there is any breakdown with convincing evidence

    1% spare parts include:

    - Wiper scraper seal

    - Tube holder

    - Screws & screw caps




    We will reply your email or fax within 24hours

    You can call us at any time if there is any question on our production.
