Flat Panel Thermal Solar Collector Low Iron Tempered Woven Glass Material

Flat Panel Thermal Solar Collector Low Iron Tempered Woven Glass Material

    • Flat Panel Thermal Solar Collector Low Iron Tempered Woven Glass Material
    • Flat Panel Thermal Solar Collector Low Iron Tempered Woven Glass Material
  • Flat Panel Thermal Solar Collector Low Iron Tempered Woven Glass Material

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 2 sqm

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Absorber Coating: Germany Blue Titanium Welding: Ultrasonic Welding
    Seal Material: EPDM Dimension Of Sub-pipe: φ10 Mm×δ0.5mm
    Header Material: Copper Collector: Flat Panel
    Cover Material: Low Iron Tempered Woven Glass Using: Villa
    High Light:

    photovoltaic thermal hybrid solar collector

    ,

    solar thermal flat plate collectors

    High Efficiency Germany Blue Titanium Flat Panel Thermal Solar Collector Low Iron Tempered Woven Glass Material



    Product Details



    Flat plate solar water heater

    1. Reliable solution
    2. Easy plug-in installation
    3. Water in tank can be used as potable water
    4. Perform better in warmer areas with lots of direct sunlight
    5. Works under high pressure
    6. Stable solar conversion during the day
    7. Back up electric heater can be used with 1500/2000/3000W
    8. Instant heat exchange, hot water can be used directly or can be used as a pre-heater
    9. Stable water output



    Features:



    1. Especially for large-scale hot water heating system, supplying hot water for apartments, hotels, restaurants, schools, hospitals, factories, swimming pools, and other places requiring large amount hot water use.

    2. Very economical and of good performance for a 15 years lifespan

    3. Adaptable to different architecture structure installation

    4. Anti-freezing system with good insulation to the pipelines

    5. Easy installation and connection of solar collectors and pipelines

    6. Able to be designed to work with auxiliary heating devices to assist solar water heating



    Description of Flat Plate Solar Collector



    • Sealed technical of metal flexibility to solve other senescent problems and keep sealed forever

    • High strength tightening locking equipment to resist the typhoon

    • All-copper with black chrome, highly selective absorber surface

    • Ultrasonic welding technical, no defect with low temperature for long-time working

    • High quality toughened glass with high luminousness to resist attack

    • Dexterous design with convenient connections, sealed and reliable





    Specifications
    Inner tank Enamel coating with low carbon steel(2.0mm)
    Inner oblong shaped tank Low carbon steel(2.5mm/3.0mm)
    Outer tank Pearl acrylic/color steel (0.41mm)
    Insulation layer Polyurethane foam (60mm)
    Enamel coil (Single/double)diameter 2.5mm
    Flat plate With copper pipelines (diameter 22mm)/black chromium or blue titanium/tempered glass (thickness 3mm)
    Heat-transfer medium Antifreeze (propylene glycol)
    Capacity 80-500L
    Frame material Galvanized steel/zinc sprayed (1.5mm)
    With accessories or not Yes
    Connection Split
    Installation angle Flexible sloppy type
    Heat preservation 72 hours
    Operating pressure 0.6MPa



    Warranty:

    1. 5 years responsibilty for free repairing or exchanging due to original quality problem;

    2. 15 years' quality guarantee for the vacuum tube.

    offering 0.3% vacuum tube free for exchanging in case several shattered ones during.



    Remark:

    1. MOQ : 1 set

    2. Loading port : Shanghai/Ningbo

    3. Payment terms : 100% T/T in advance for the sample;30% advanced payment by T/T or

    L/C,The balance 70% by T/T or L/C against the Copy of B/L for the container.

    4.Supply ability : 150 sets per day

    5. Delivery time : 7-15 days after receive your deposit.



    FAQ

    Model selection:

    We suggest 40 - 50 liter hot water for one person in a single day, for colder area larger aperture area is suggested for same tank liter.



    Optional device:

    Choose by yourself or rely on our 10 years export experience for consultation.



    Connection:

    Size and location for tank connection can be customized or suggested by our experienced stuff.



    OEM:

    Your LOGO information can be on the flat plate solar water heater and carton boxes.



    ODM:

    Design can be made according to your actual requirements.
