Laser Welding Solar Thermal Flat Plate Collectors With Black Chrome Coating Absorber

Laser Welding Solar Thermal Flat Plate Collectors With Black Chrome Coating Absorber

    • Laser Welding Solar Thermal Flat Plate Collectors With Black Chrome Coating Absorber
    • Laser Welding Solar Thermal Flat Plate Collectors With Black Chrome Coating Absorber
  • Laser Welding Solar Thermal Flat Plate Collectors With Black Chrome Coating Absorber

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 2 sqm

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Absorber Coating: Black Chrome Welding: Laser Welding
    Work Pressure: 0.6Mpa Absorber Material: Aluminum Belt Plate
    Collector: Flat Panel Dimension Of End Pipe: φ22 ×δ0.6mm
    Using: Heating Gross Area (m2): 2
    High Light:

    solar thermal collectors

    ,

    photovoltaic thermal hybrid solar collector

    High Heat Efficient Flat Panel Thermal Solar Collector With Black Chrome Coating Absorber



    Description of Flat Plate Solar Collector



    • Sealed technical of metal flexibility to solve other senescent problems and keep sealed forever

    • High strength tightening locking equipment to resist the typhoon

    • All-copper with black chrome, highly selective absorber surface

    • Ultrasonic welding technical, no defect with low temperature for long-time working

    • High quality toughened glass with high luminousness to resist attack

    • Dexterous design with convenient connections, sealed and reliable



    Features of Flat Plate Solar Collector



    1. Most wide-used and practical collector in solar water heating system;

    2. Wide applications for water heating, pool heating, space heating;

    3. Large solar heating capacity up to 500,000 Liter hot water;

    4. Much safe and stable performance with little maintenance;

    5. Very efficient direct or indirect solar water heating;

    6. Strong adaptability to flat or slope roof installation;

    7. Easy installation and connection with simple structure;

    8. Super anti-freezing performance with glycol-water mixture;

    9. Applicable to passive and active solar water heating system;

    10. 10 years project installation experience for consultation.



    Application for Flat Plate Solar Collector



    Flat plate solar thermal collector is suitable for residential or commercial solar water heating projects, such as hot water for real estates, hotels, factories, hospitals, schools, swimming pools, space or floor heating, etc.



    Model A-2000/1000/80 B-2000/1000/80 C-2000/1000/80 D-2000/1000/80
    Coating Anode Oxidation Black chrome Black chrome Blue coating
    Welding Laser Ultrasonic Laser Laser
    Material of Absorber Copper & Aluminum Copper Copper & Aluminum Copper & Aluminum

    Size & Quantity

    header pipe

    22*08mm 2PCS

    Size &Quantity

    branch pipe

    10*0.6mm 7PCS
    Absorption rate 0.90±0.03 0.93±0.03 0.92±0.03 0.94±0.02
    Reflection rate 0.18±0.05 0.10±0.05 0.10±0.05 0.05±0.02
    Collector size 2000 x 1000 x 80mm
    Frame color Silver/Black/Champagne
    Gross area 2m2
    Absorber area 1.85m2
    Sealing EPDM
    cover material Ultra white and low iron fabric surface tempered glass
    Cover transmission 92%
    Back plate material 0.30mm galvanized steel
    Insulation 30mm glass wool
    Max working pressure 0.6MPa
    weight 37kg 37kg 38kg 38kg



    QC Team



    A QC team with more than 10years’ experience and technical personnel.

    To ensure 100% products checking.

    Material:

    Strictly control of material purchasing and using, meet international requested standards



    Semi-finished products inspection:

    Product inspection before 100% finished, such as visual inspection, leaking and pressure testing, comprehensive safety test and so on.



    Production line test:

    With work team or data engineer who will inspect machines and lines at fixed period.



    Finished product inspection:

    Quality and property test before products are packed and loaded.



    Quality Guarantee



    We provide 5years warranty of products and shipment with 1% spare parts



    We can send the parts free on condition that there is any breakdown with convincing evidence

    1% spare parts include:

    - Wiper scraper seal

    - Tube holder

    - Screws & screw caps



    Contact



    We will reply your email or fax within 24hours

    You can call us at any time if there is any question on our production
