Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment

Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment
Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment

Large Image :  Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 30tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment

Description
Tubes: 30 Tubes Insulation: Rock Wool
Mounting: Aluminum Alloy Installation: Inclined Roof
Heat Pipe: 14mm Condenser Manifold Color: Silver
Collector: Heat Pipe Application: Apartment
High Light:

solar thermal collectors

,

photovoltaic thermal hybrid solar collector

14mm Condenser High Efficiency Heat Pipe Thermal Solar Collector 30 Tubes Rock Wool



Specifications:



This model can withstand high pressure (6 bar ) working, and can meet the demand of large water consumption.

It has anti-freezing function (>-35C), because all the pipelines are made of red copper and conducted by heat transfer medium liquid, no water flows into the tubes when working.

It can still work well even one tube is broken. Also, it is easily installed on the pitched roof or flat roof.



Technical Data



Manifold (interior) : Red copper

Manifold (exterior) : Aluminum alloy

Aluminum fin : 1620mm full length

Heat pipe : Red copper

Insulation Layer : Eco-friendly rockwool 50mm

Vacuum tube : 58*1800mm/SS-CU-ALN coating

Bracket : Aluminum alloy with 27/30/38/45 degree installing angle

Manifold connection (inch) : 3/4

Note : All the systems are available for the customization.



Three-target Vacuum Tube Performance and Specification:
Tube structure All-glass double deck co-axial structure
Glass material High borosilicate 3.3 glass
Outer tube diameter and glass thickness Ø58±0.7mm; Glass thickness 1.6±0.15mm
Inner tube diameter and glass thickness Ø47±0.7mm; Glass thickness 1.6±0.15mm
Tube dimension 58*1800mm
Absorption
coating
property
Coating material CU/SS-ALN(H)/SS-ALN(L)/ALN
Sediment method Three Target magnetron sputtering plating
Absorptivity α =0.92~0.96 (AM1.5)
Emission ratio Emission: ε=0.04~0.06(80°C±5°C)
Vacuum degree P≤5.0X10-3(PA)

Stagnation temperature

(temperature inside of empty evacuated tubes)

260~300 °C
Average heat loss ULT 0.4~0.6 W/(m2 *°C)
Hail resistance Ø25 mm
24mm Premium Heat Pipe Performance and Specification:
Heat pipe material Oxygen free copper (TU1),Cu=Ag>99.99%(o2<16ppm)
Condenser dimensions Top: Ø24mm *65mm,Body: Ø8*0.6mm.length:1750± 10mm
Heat-transfer-fins 0.3mm/0.0098’’ thick sets of Aluminum fins,1630mm
Starting speed 30s
Max. operation pressure 6bar
Max. testing pressure 12bar
Stagnation temperature 236°C
Manifold Performance and Specification:
Manifold header pipe TU2 copper
Manifold casing Anodized aluminum alloy (6063-T5/T6)
Insulation layer Compressed rock wool.
Bracket Performance and Specification:
Bracket 2.0mm thickness aluminum alloy bracket.
Vertical installation angle Flat & pitched roof



Optional Accessories



Split Controller

Wilo-Star-Rs 15/6 (Circulation)

Collector Mounting Bracket (Mounting&fixing)

Copper Connector

Flexible Steel Pipe (connection)

Working station
