Product Details:
|
| Size: | G1/2",G3/4",G1" | Material: | Brass |
|---|---|---|---|
| Type: | Solar Water Heater Accessories | Nominal Pressure: | 1.6Mpa |
| Working Media: | Water, Oil, Gas | Working Temperature: | -20C≤t≤150C |
| Temp Adjust Range: | 20-50C | Pressure Test: | In Accord With ISO5208 |
| High Light: | Brass Valve Solar Water Heater Accessories,Mixing Valve Solar Water Heater Accessories,Brass Hot Water Mixing Valve |
||
Hot Water Mixing Valve Cold Mix Valve Solar Water Heater Copper Brass Valve
Solar Water Heater Accessories New Brass Adjustable Water Thermostatic Mixing Valve
Technology parameters:
Mixed water temperature range:35----60℃
set temperature:55℃
Mixed water temperature accuracy:±2℃
Hot water temperature range:55-100℃
Cold water temperature range:5-25℃
Cold water, hot water working pressure range: 0.5--5bar
Maximum allowable allows the static pressure:16bar
Maximum flow:40L/min
Specification: DN15,DN20
Product standards:EN1111,AS4032
Mixing valve materail:HPb59-1;
Piston material:PPO
Spring material:stainless steel304;
Sealing pieces of material:EPDM
Handle Material:ABS
Surface treatment:Sandblasted nickel-plated;
Installation
Before installing the mixing valve,cleaning of the system and make sure no Impurities in it;
In order to make the mixing valve working normally, It should be installed according to the drawing as follow; hot water pipe must connect with A section marked with an "H" and cold water pipe must connect with A section marked with an "C"; Mixing pipe can connect with A section marked with an "MIX"; Mixing valve can be installed Horizontal and vertical installation
| Storage Tank | |||
| Capacity | 100Lt | 150Lt | 200Lt |
| Inner Tank Material | Stainless Steel | Stainless Steel | Stainless Steel |
| Inner Tank Diameter | 360mm | 360mm | 360mm |
| Insulation Material | Polyurethane | Polyurethane | Polyurethane |
| Insulation Thickness | 50mm | 50mm | 50mm |
| Insulation Density | 36kg/m² | 36kg/m² | 36kg/m² |
| Outer Tank Material | Colored Steel | Colored Steel | Colored Steel |
| Outer Tank Diameter | 460mm | 460mm | 460mm |
| Frame | |||
| Material | Powder-coating Zinc | Powder-coating Zinc | Powder-coating Zinc |
| Collector Tubes | |||
| Outer Tube Diameter | 58mm | 58mm | 58mm |
| Material | High Borosilicate glass | High Borosilicate glass | High Borosilicate glass |
| Tube NO. | 12 | 15 | 20 |
| Thickness | 2.0-2.2mm | 2.0-2.2mm | 2.0-2.2mm |
| Inner Tube Diameter | 47mm | 47mm | 47mm |
| Material | High Borosilicate glass | High Borosilicate glass | High Borosilicate glass |
| Aperture Area m² | 0.96m²(1.7mx0.047mx12) | 1.2m²(1.7m*0.047m*15) | 1.63m²(1.7m*0.047m*20) |
| Peformance | |||
| Q factor(System Output) | 14.454(16MJ/m²) | 16.090(16MJ/m²) | 25.063(16MJ/m²) |
| Hail Test | Hail Resistance/25mm | Hail Resistance/25mm | Hail Resistance/25mm |
| Freeze Test | Freeze Resistance | Freeze Resistance | Freeze Resistance |
| Note:In order to allow for continuous improvement,Apollo Technology reserves the right to update and change specifications without prior notice |
