Black Pressurized Thermal Solar Collector Heat Pipe For Swimming Pool

Black Pressurized Thermal Solar Collector Heat Pipe For Swimming Pool
Black Pressurized Thermal Solar Collector Heat Pipe For Swimming Pool Black Pressurized Thermal Solar Collector Heat Pipe For Swimming Pool Black Pressurized Thermal Solar Collector Heat Pipe For Swimming Pool

Large Image :  Black Pressurized Thermal Solar Collector Heat Pipe For Swimming Pool

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 30tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

Black Pressurized Thermal Solar Collector Heat Pipe For Swimming Pool

Description
Tubes: 30 Tubes Insulation: Polyurethane
Mounting: Aluminum Alloy Installation: Inclined Roof
Heat Pipe: 14mm Condenser Copper, Nickel Plated Manifold Color: Black
Collector: Heat Pipe Application: Swimming Pool
High Light:

solar thermal collectors

,

photovoltaic thermal hybrid solar collector

High Temperature Black Pressurized Heat Pipe Thermal Solar Collector With 30 Tubes



Features:


1) Reliable and efficient twin-glass solar tubes
2) Copper heat pipes for rapid heat transfer
3) Easy plug-in installation
4) Free maintenance
5) Suitable for mains pressure water
6) Corrosion resistant silver brazed copper header
7) The surface is made of powder coated galvanized steel
8) Stable solar conversion during the day
9) The perfect solar collector for domestic solar water heater systems
10) Ideal for commercial solar water heating applications

How it works:


1) The operation of the solar collector is very simple.
2) Solar absorption: solar radiation is absorbed by the solar tubes
and converted into heat.
3) Solar heat transfer: heat pipes conduct the heat from within the
solar tube up to the header pipe
4) Solar energy storage: water is circulated through the header,
via intermittent pump cycling. Each time the water circulates through
the header, the temperatures is raised by 5-10C. Throughout the day,
the water in the tank is gradually heated.



Three-target Vacuum Tube Performance and Specification:
Tube structure All-glass double deck co-axial structure
Glass material High borosilicate 3.3 glass
Outer tube diameter and glass thickness Ø58±0.7mm; Glass thickness 1.6±0.15mm
Inner tube diameter and glass thickness Ø47±0.7mm; Glass thickness 1.6±0.15mm
Tube dimension 58*1800mm
Absorption
coating
property
Coating material CU/SS-ALN(H)/SS-ALN(L)/ALN
Sediment method Three Target magnetron sputtering plating
Absorptivity α =0.92~0.96 (AM1.5)
Emission ratio Emission: ε=0.04~0.06(80°C±5°C)
Vacuum degree P≤5.0X10-3(PA)

Stagnation temperature

(temperature inside of empty evacuated tubes)

260~300 °C
Average heat loss ULT 0.4~0.6 W/(m2 *°C)
Hail resistance Ø25 mm
24mm Premium Heat Pipe Performance and Specification:
Heat pipe material Oxygen free copper (TU1),Cu=Ag>99.99%(o2<16ppm)
Condenser dimensions Top: Ø24mm *65mm,Body: Ø8*0.6mm.length:1750± 10mm
Heat-transfer-fins 0.3mm/0.0098’’ thick sets of Aluminum fins,1630mm
Starting speed 30s
Max. operation pressure 6bar
Max. testing pressure 12bar
Stagnation temperature 236°C
Manifold Performance and Specification:
Manifold header pipe TU2 copper
Manifold casing Anodized aluminum alloy (6063-T5/T6)
Insulation layer Compressed rock wool.
Bracket Performance and Specification:
Bracket 2.0mm thickness aluminum alloy bracket.
Vertical installation angle Flat & pitched roof



Packaging & Delivery



Packaging Details:

1. Standard export packing for FCL order.
2. Special packing for LCL order.



Delivery Detail:

10-15 days after receipt of deposit
