CE Certified Heat Pipe Solar Collector , Solar Heat Pipe Collector Multi Function

CE Certified Heat Pipe Solar Collector , Solar Heat Pipe Collector Multi Function
CE Certified Heat Pipe Solar Collector , Solar Heat Pipe Collector Multi Function CE Certified Heat Pipe Solar Collector , Solar Heat Pipe Collector Multi Function CE Certified Heat Pipe Solar Collector , Solar Heat Pipe Collector Multi Function CE Certified Heat Pipe Solar Collector , Solar Heat Pipe Collector Multi Function

Large Image :  CE Certified Heat Pipe Solar Collector , Solar Heat Pipe Collector Multi Function

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 10tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

CE Certified Heat Pipe Solar Collector , Solar Heat Pipe Collector Multi Function

Description
Heating Collector: 10 Tubes Insulation Material: Rock Wool
Bracket: Aluminum Alloy Installation: Pitched Roof
Heat Pipe: 14mm Condenser Copper Manifold Color: Silver
Certification: CE Certifited Application: Heating
High Light:

heat pipe vacuum tube solar collector

,

solar hot water collector

CE Certifited Aluminium Alloy Reflector Rock Wool Heat Pipe Solar Collector 10 Tubes



Heat pipe solar collector
1) For 5 years warranty!
2) 2% FREE SPARE PARTS!
3) Sample offer!
4) OEM service!



Working principle



Split pressurized solar water heater has solar collectors on roof and water tanks inside the house. When the difference of collector temperature and tank temperature gets to the set value, the circulation system will start work. It will transmit the solar energy from solar collector to the tank.



1) The operation of the solar collector is very simple.
2) Solar absorption: solar radiation is absorbed by the solar tubes and converted into heat.
3) Solar heat transfer: heat pipes conduct the heat from within the solar tube up to the header pipe
4) Solar energy storage: water is circulated through the header, via intermittent pump cycling. Each time the water circulates through the header, the temperatures is raised by 5-10 C. Throughout the day, the water in the tank is gradually heated



Specifications

1. Manifold (interior) material: red copper

2. Manifold (exterior) material: aluminum alloy

3. Tube dimensions: 58 x 1.800 mm / 47 x 1.500 mm

4. Vacuum tube coating material: AL-N-AL or AIN-SS-Cu

5. Insulation layer: rock wool

6. Pressure bearing: 6Bar=0.6MPa

7. Hail resistance: 25mm

8. The standards of vacuum tubes with heat pipe: 14, 16, 18, 20, 24, 30 tubes .

9.Water capacity: 150L, 200L, 250L, 300L, 500L
10.Daily efficiency: >= 55%(>=42% in winter)
11. Heat preservation: 72h to 80h
12. Electric heater: 1.5Kw to 3Kw



Warranty
5 years' International responsibility for free repairing or exchange due to original quality problem
Remark :
a) We offer 2% vacuum tubes for free for exchange in case several shattered vacuum tubes during transit
b) About the following accessories, if you need, we can offer it to you, but should charge it.



Model Ligthing
(m2)
Heat pipe Supply hot
water(L/D)
20/40" container
diameter length No.
PT47/12 1.26 Ø47mm 1500mm 12 70 233/566
PT 47/18 1.80 18 110 164/400
PT 47/20 2.10 20 125 130/380
PT 47/30 3.15 30 180 103/251
PT 58/12 1.73 Ø58mm 1800mm 12 110 127/309
PT 58/18 2.57 18 150 100/242
PT 58/20 2.88 20 175 90/230
PT 58/30 4.32 30 260 68/165



Remarks:



Payment:

For LCL/Sample order, the wooden box fee and inland transportation fee will charge for extra, we accept 100% T/T in advance;

For FCL order, we accept 30% T/T in advance, 70% balance is upon the copy of B/L.

Warranty:

15 years for the vacuum tubes; for solar glass vacuum tube, we will send 1% of all tubes as compensation for free.

Delivery time:

within 3 days for sample order; within 12 days for standard container, within 15 days for OEM order;

Packing details:

If LCL/sample order, in order to avoid be broken in shipping, we will pack the tubes with wood box.

FCL Order: export standard carton, five layers hard paper carton with safety foam in every carton.
