24mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector

24mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector
24mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector 24mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector 24mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector

Large Image :  24mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 10/15/18/20/24/25/30tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

24mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector

Description
Tubes: 10/15/18/20/24/25/30tubes Reflector: CPC Reflector
Frame: Aluminum Alloy Installation: Pitched Roof
Heat Pipe: 24mm Condenser Copper Structure: Heat Pipe
Angle Of Bracket: 0/30/45 Degree Application: Shower
High Light:

24mm Condenser Copper Solar Collector

,

24mm Condenser Solar Collector

,

20tubes Heat Pipe Solar Heating Collector

24mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector



Specifications of heat pipe solar collector


1. Vacuum Tube: borosilicate glass 3.3
2. Tube Coating: AL-N/SS/Cu (Tri-elements)
3. Tube Dimension : dia58mm*1800mm
4. heat pipe: 14mm diameter heat pipe tip. length:1720mm
5. Manifold casing material: aluminum alloy
6. Heat channel:TU2 copper
7. Insulating layer:polyurethane and mineral wool
8. Frame: 2.0mm aluminum alloy
9. Anti-Freeze: -35C
The Collector are with Solar Keymark, SRCC, CCC, ISO9001:2000 certificates.



Unit including



a). heat pipe solar collector tubes
b). manifold.
c). 2.0mm Aluminum Alloy free standing bracket





Working Principle



high pressure heat pipe solar collector is one of the most popular solar collector with pretty high efficiency.

The selective coating of vacuum tubes converts solar irradiation into heat energy and transfers to copper heat pipes by aluminum wrapping.

The heat transfer liquid in heat pipe then vaporize and rapidly rise to the top condenser.

In active system, a pump circulates water or heat transfer fluid through the manifold header pipe, taking away the heat to store in tank water.

The cooled vapor in heat pipe then liquefies and returns to pipe bottom, waiting for another heat circulation in few seconds.



Heat Pipe Solar collector
Model Tube Specification Tube Coating

Daily Output

(50C) (L)

Loading Quantity
20'GP (sets) 40'GP (sets) 40'HQ (sets)
10-58/1800 Φ58mm*1800mm*10 14mm 85-120 130 270 325
15-58/1800 Φ58mm*1800mm*15 14mm 105-150 110 230 275
20-58/1800 Φ58mm*1800mm*20 14mm 140-200 85 170 210
25-58/1800 Φ58mm*1800mm*25 14mm 180-220 70 135 180
30-58/1800 Φ58mm*1800mm*30 14mm 210-300 55 115 140



Specification



Model 58*1800
Size of Condenser 24*70mm/14*70mm
Length of glass tube 1800mm
Outer tube diameter 58mm
Inner tube diameter 47mm
Glass thickness 1.6mm
Glass material Borosilicate Glass 3.3
Absorptive coating ALN/ALN-SS/CU
Absorption coefficient

>92%



Our service



We have both vacuum tubes factory and water tank factory for more than 8 years.

We provide 6 years Warranty for the whole system.

Keep the delivery time exact.

Your inquiry will be replied within 12 hours.

We offer you professional service with fluent English.

Keep the bulk production as the samples in high quality.

Freight forwarder: faster, safer and convenient.

Quality : we have QC in each process.



Packaging & Delivery



Packaging Details: Export carton for full container.

Delivery Detail: 7 days after receiving the deposit.



Warranty



6 years international responsibility for heat pipe solar collector and 15 years for vacuum tubes due to original quality problems.

24mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector 024mm Condensor Solar Collector 20tubes Heat Pipe Solar Heating Collector 1
