Copper Coil Solar Hot Water Heater System

Copper Coil Solar Hot Water Heater System
Copper Coil Solar Hot Water Heater System Copper Coil Solar Hot Water Heater System

Large Image :  Copper Coil Solar Hot Water Heater System

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 300L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

Copper Coil Solar Hot Water Heater System

Description
Capacity: 300L Tank Colour: White
Heat Exchanger: Copper Coil Structure: Split
Outer Tank: Color Steel Inner Tank: Stainless Steel 304
Use: House Used Heat Preservation: 3 Days
High Light:

residential solar water heater

,

split pressurized solar water heater

300L White Active High Temperature Copper Coil Split Solar Water Heater for House Used



Application

Mainly for family shower/bath

How to choose
Choose the item according to the capacity, and choose the capacity according to the people quantity in your family, one adult shower need about 50L water.



STRUCTURE of Split Pressurized Solar Water Heater

The split solar water heater is composed by solar heat collector, cylinder water tank and working

station( pump station).

1. Collector: heat pipe, or U pipe

2. Tank: pressure tank, 100L-1500L

3. Work station



Working principle


1. The collector absorbs solar energy and transmits it to the water tank through circulation .
2. When the temperature of the collector reaches the set value, the controller starts the circulation pump automatically.
3. The circulation pump makes heat-conducting liquid circulate automatically.
4. The heat-conducting liquid transfers heat to water by lower heat exchanger in the water tank.
5. When the temperature difference between solar collector and tank doesn't reach the set value, the circulation pump will be shut automatically .
6. In case the temperature of the water tank does not reach Tmax, Electric Heating Element will start to work automatically.



Features



1. Strong hydraulic pressure makes your bathe more comfortable.

2. module design, arbitrary combination, harmonious with the building perfectly.

3. Intelligent controlling and multiple functions.

4. Arbitrary combination with structure of your beautiful constructions.

5. Separate installation conveniently.

6. workable at anytime and enjoyable.

7. Working with assistant resource.

8. Full set of original equipment, the life time will be much longer to ensure better using.


Specification



Name Split pressurized solar water heater
Material of out manifold 0.31-0.55mm thickness color steel/ fluorine carbon steel
Material of inner tank Food grade 1.2-2.0 mm thickness SUS304 stainless steel
Material of outer tank colour steel or stainless steel
Inlet and outlet hole Male G3/4
Max pressure 0.6 Mpa
Solar collector tube 3.3 Borosilicate glass with SS-ALN(L)/ALNor CU/SS/ALN coating
Thickness of glass tube 1.6mm
Vacuum tube tightness P≤0.005 Pa
Absorption as=0.93-0.96(AM1.5)
Emission ratio εh=0.04-0.06(80C±5C)
Idle sunning property parameters Y=220~260m2.C/KW
Average heat loss coefficient ULT=0.6~0.7W/(m2.C)
Bracket: 2.0mm thickness aluminum alloy
Welding: Argon arc welding
Fastening pieces: Made of stainless steel screw
Tank capacity 100L,150l,200L,300L,500L,800L,1000L
Solar collector 10/12/15/18/20/24/30 tubes
OEM Provide
Working station SP116,SP228
Heat exchanger length 18m



Split Pressurized Solar Water Heater
Model Tube

quantity
Tank
Capacity
(Liter)

Copper coilers

length(m)

Packing size
(CBM)
Loading quantity(sets)
20'GP 40'GP 40'HQ
With double coilers in the water tank(35-50m copper coil as heat change material)
PT2-100 10 100 10+10 0.587 48 98 115
PT2-150 15 150 12+10 0.670 41 85 101
PT2-200 20 200 15+10 0.860 32 67 79
PT2-250 25 250 18+12 1.070 25 54 63
PT2-300 30 300 18+12 1.210 23 47 55
PT2-400 40 400 22+15 1.466 20 40 47
PT2-500 50 500 25+15 1.534 19 38 45
PT2-600 60 600 30+18 2.330 12 24 30
PT2-700 70 700 35+18 2.780 10 20 25
PT2-800 80 800 40+20 3.065 9 17 22
PT2-1000 100 1000 50+30 3.975 7 14 18



FAQ



Payment terms: T/T, L/C, Paypal, Western union all support.

Delivery time: Sample order 3 working days, Container order 10 working days.

Minimum order quantity: 1 PC

Guarantee period: 8 years

OEM service: Support (Print logo on carton for free)
