|Outer Tank:||Stainless Steel||Inner Tank:||Stainless Steel 304|
copper pipe solar water heater,
solar energy water heater
200L Food Grade Integrative Pressurized Mini Portable Silver Heat Pipe Solar Water Heater
● Highly efficient absorber of high performance with daily average efficiency over 50%
● Start up quickly, heat pipe transfer the heat energy into the storage tank in one direction
● Withstand pressure of 6 Bar, can be connected directly with city water
● No water inside the evacuated tubes, solar water heater can still in service even with several tubes breakage
● Highly efficient insulation with polyurethane foam
● Simple structure, easy to assembly and install, simple structure, easy to assembly
● Can be used all year round in the cold climate area
● Can be used together with auxiliary electric boost
● Long service life, can be used over 15 years
Vacuum tube: super conducted heat pipe (without water)
Insulation tank: SUS304, SUS-316L pressurized inner tank
Working pressure: 6 bar
T/P valve: 6 bar/99°C
Working principle: direct working withstand pressure
Frame: slope and flat roof multifunction
Assistant function: electric heater
1. The compact pressurized solar water heater system can endure the max pressure up to 0.6Mpa.
As the system is pressurized,so it can keep a constant temperature of water in the tank.
2. There is no water in the vacuum tube.
so even if the vacuum tube broken,the system still works normally, without water leakage.
The copper pipe inside the vacuum tube could quickly transfer the heat into the water tank through the liquid medium inside the copper pipe.
3. It can endure the freezing -35 degree centigrade and 25mm hailstone.
4. For inner tank, we adopt high frequent melting technology.
It can directly connect with tap water system.
The pressurized water tank has no exhaust hole.
therefore, it must bear the pressure came from tap water and hot water.
When use, the hot water comes out because of water pressure.
Vacuum tube absorbs solar energy, and conductive copper pipe transfers the heat into the pressurized water tank.
In this case, the water inside the tank becomes hot.
No water in the heat pipe makes the whole system could bear pressure.
Lead Time /
|Delivery Details||15 days when we get your advanced payment|
|Packing Info||exported standard cartons|
|Target Market(s)||Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe|
1. Electric heater:1500W-2000W/220V-230V;
2. Intelligent controller: SR609(esp. for integrative pressurized type);
3. P/T valve (pressure & temperature): WAY-20,0.7MPa;
4. Magnesium rod:diameter 20mm, length 23 cm, copper connector;
5. Temperature sensor;
6. Air vent valve;
7. Vacuum valve;
8. Check valve.
1. What is your Delivery Time?
Full container order:15days.
2. What is your Guarantee Time?
6 years; Provide you with some accessories, they are free for you.
3. Can you accept OEM and ODM ?
YES, printing your LOGO on the product and package, it's free.
4. What is your payment term?
We accept T/T or L/C, Western Union and Paypal.
5. What is your MOQ?
6. Low do you pack?
LCL order in plywood case
Full container order in high quality export carton
7. What is your FOB port?
We accept FOB Shanghai, Ningbo, Shenzhen, Guanagzhou, Qingdao etc.
8. What is your monthly production capacity?
9. What is your shipping term?
10. Do you any additional services?
We offer free spares according to your order quantity. Such as Vacuum Tube, tube holders, dusting rings, silicon rings, screws etc.
And we can offer logo design, Products Advertising Design etc services free.
