250L Pressure Solar Water Heater 30tubes High Pressure Heat Pipe Solar Collector

250L Pressure Solar Water Heater 30tubes High Pressure Heat Pipe Solar Collector
250L Pressure Solar Water Heater 30tubes High Pressure Heat Pipe Solar Collector 250L Pressure Solar Water Heater 30tubes High Pressure Heat Pipe Solar Collector 250L Pressure Solar Water Heater 30tubes High Pressure Heat Pipe Solar Collector

Large Image :  250L Pressure Solar Water Heater 30tubes High Pressure Heat Pipe Solar Collector

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 300L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

250L Pressure Solar Water Heater 30tubes High Pressure Heat Pipe Solar Collector

Description
Capacity: 300L Working Pressure: 6 Bar
Insulation: 55mm High Pressure Polyurethane Foam Structure: Integrative
Principle: Pressured Outer Tank: White Tank
Inner Tank: Stainless Steel 316 Collector: Heat Pipe
High Light:

6 Bar Heat Pipe Solar Heater

,

High Pressure 250L Water Heater

,

Integrative Structure 250L Water Heater

250L Pressure Solar Water Heater 30tubes High Pressure Heat Pipe Solar Collector



Description



Material of out tank: 0.4mm thickness color steel/ fluorine carbon steel

Material of inner tank: Food grade 1.2mm thickness ,SUS304-2B stainless steel

Tank insulating layer: 55mm 45kg/m³ high-density polyurethane foamed

Inlet and outlet hole: Male G 1/2, 3/4

Max pressure: 0.6Mpa

Solar collector tube: 3.3 Borosilicate glass with N/Al coating

Thickness of glass tube: 1.6mm

Vacuum tube tightness: P≤0.005 Pa

Absorption: as=0.93-0.96(AM1.5)

Emission ratio: εh=0.04-0.06(80C±5C)

Idle sunning property parameters: Y=220~260m2.C/K

Average heat loss coefficient: ULT=0.6~0.7W/(m2.C)

Bracket: 1.5mm thickness Galvanized Steel

Structure of tank: 5 holes for air vent,water inlet and outlet,electric heater,Mag Rod

Welding: Argon arc welding

Fastening pieces: Made of stainless steel screw

Absorber area: 2.125 m²

Tube quantity: 30tubes, 58x1,800mm with heat pipe

Tank capacity: 300L



Working Principle:



1. The pressurized water tank has no exhaust hole, therefore, it must bear the pressure came from tap water and hot water,when use, the hot water comes out because of water pressure.

2. Vacuum tube absorbs solar energy, and conductive copper pipe transfers the heat into the pressurized water tank. In this case, the water inside the tank becomes hot.

3. No water in the heat pipe makes the whole system could bear pressure.



Features:



1. Adopts the best conduction performance metal- heat pipe (copper).
2. Can be used all year round in the cold climate.
3. High efficiency, rapid warming. Heat pipe in vacuum tube could transfer hot energy to cold water in pressurized water tank rapidly.
4. The whole pressure of the system is up to 1.5kg/M2, the inlet could connect the tap water directly, the max pressure can be 0.6Mpa.
5. No water in the tube, one tube broken don't influence the system working.
6. The design for inner tank is reasonable and scientific, which could hold 100, 000 times fatigue test without any damage.
7. Dual-purpose brackets for both flat and inclined roof.

8. The system is pressurized,it keep a constant temperature of water in the tank, avoid the problem came from water level controller malfunction which could cause water flow out.



Advantage:



1. The pressure of hot water is pressure of tap water directly ,you can enjoy more comfortable shower.

2. Hot water that we use flow in copper coil without transferring in tank directly ,so the water is more clean and healthy.

3. There is no need to wait , you can enjoy instant hot water at any time .

4. It is suitable for some area special with bad water quality such as hard water ,impurity water etc.We only need use high quality water in tank as a thermal source,refresh it during some time in interval.This will increase vacuum tube heat efficiency and in ease whole system life performance.

5. Can be used all year round in the cold climate.

6. Simple structure, easy to assembly and install, diffuse flat plate reflector can be assembled easily with its module structure.



Remarks:



1. Lead-time:7-15 working days after receiving payment.

2. Payment Term:T/T, L/C, Western Union.

3. Warranty:5 years for the full system, 15 years for the vacuum tube,and 1year for accessories.

4. Trade Term: FOB, CFR and CIF.



Accessories:



1. Electric heater:1500W-2000W/220V-230V;

2. Intelligent controller: SR609(esp. for integrative pressurized type);

3. P/T valve (pressure & temperature): WAY-20,0.7MPa;

4. Magnesium rod:diameter 20mm, length 23 cm, copper connector;

5. Temperature sensor;

6. Air vent valve;

7. Vacuum valve;

8. Check valve.



Specifications:



Model PT-H-10 PT-H-15 PT-H-18 PT-H-20 PT-H-24 PT-H-25 PT-H-30
Storage Tank 100L 150L 180L 200L 240L 250L 300L
Inner Tank Stainless Steel SUS304 2B/SUS316L
Outer Tank Colored Steel( Sliver/White )/SUS201/SUS304 2B/SUS316L
Insulation Layer High Density Polyurethane Foaming
Tube QTY(PCS) 10 15 18 20 24 25 30
Dustproof Rubber EPDM
Dsily Heat Gain 8.5MJ/m²
Work Pressure 0.6MPa
Three Target Vacuum Tube Diameter/Length: φ58mm/1800mm; High boron and silicon content 3.3; Structure:Gradual change SS-AL-Nx/Cu selective absorption coating; Vacuum Degree:P<=5*10-3;
Heat Pipe Condesor: φ14*70mm; Thickness: 0.5mm ; Material: red copper TU1+water; Transfer Power:>=150W; Working Pressure:4Mpa; Welding Pressure:4Mpa;
Bracket Galvanized Steel with Plastic Coating in Black color/Aluminum Alloy/SUS201/SUS3042B/SUS316L, 0/20/30/45 degrees
Contour Aperture Area 1.23m² 1.84m² 2.22m² 2.47m² 2.96m² 3.08m² 3.70m²
Aperture Area 0.95m² 1.42m² 1.70m² 1.89m² 2.27m² 2.36m² 2.83m²
Absorption Area 0.82m² 1.22m2 1.46m2 1.62m2 1.96m² 2.04m² 2.43m²
Accessories(Optional) T/P Valve,Electrical Heater & Magnesuim Bar
OEM Service: Logo painting on products and package is for free (20FT,40FT,40HQ)



FAQ:

1. What is your Delivery Time?

LCL order:10days.

Full container order:15days.

2. What is your Guarantee Time?

6 years; Provide you with some accessories, they are free for you.

3. Can you accept OEM and ODM ?

YES, printing your LOGO on the product and package, it's free.

4. What is your payment term?

We accept T/T or L/C, Western Union and Paypal.

5. What is your MOQ?

4 sets

6. Low do you pack?

LCL order in plywood case

Full container order in high quality export carton

7. What is your FOB port?

We accept FOB Shanghai, Ningbo, Shenzhen, Guanagzhou, Qingdao etc.

8. What is your monthly production capacity?

1000 sets

9. What is your shipping term?

By sea/Air/Rail/Truck

10. Do you any additional services?

YES!

We offer free spares according to your order quantity. Such as Vacuum Tube, tube holders, dusting rings, silicon rings, screws etc.

And we can offer logo design, Products Advertising Design etc services free.
