500L Split Pressure Solar Water Heater Evacuated Tube Heat Pipe Solar Collector

500L Split Pressure Solar Water Heater Evacuated Tube Heat Pipe Solar Collector
500L Split Pressure Solar Water Heater Evacuated Tube Heat Pipe Solar Collector 500L Split Pressure Solar Water Heater Evacuated Tube Heat Pipe Solar Collector 500L Split Pressure Solar Water Heater Evacuated Tube Heat Pipe Solar Collector 500L Split Pressure Solar Water Heater Evacuated Tube Heat Pipe Solar Collector

Large Image :  500L Split Pressure Solar Water Heater Evacuated Tube Heat Pipe Solar Collector

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 500L
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negotiable
Packaging Details: CARTON/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

500L Split Pressure Solar Water Heater Evacuated Tube Heat Pipe Solar Collector

Description
Outer Tank: Colored Steel/Stainless Steel Inner Tank: SUS304 2B/316
Bracket: Galvanized Steel With Plastic Coated Insulation Layer: High Presure Polyurathane Foaming
Heat Pipe: 14mm/24mm Condenser Circulation Type: Indirect / Closed Loop (Active)
Working Pressure: 0.6Mpa Test Pressure: 1Mpa
High Light:

residential solar water heater

,

high pressure solar water heater

Description:

The split solar water heater is an active system,because it uses a pump with a controller to circulate the fluid in the system.

Storage thank and solar collector are separate,while the collector is integrated in to the roof of the building,the tank and the pump station can be installed anywhere of the building.

The piping between the main components is made of brass and a special insulation with high temperature resistance for solar systems.

This system is especially suitable for cold area, even -35 celsius degrees .

Now ,the split solar water heater is more and more popular in the world.



Working Principle:

1.When the temperature of the heat pipe collector reaches the set valve, the controller shall start the circulation pump automatically.

2.The circulation pump makes heat-conducting liquid circulate automatically.

3.The heat-conducting liquid transfer heat to water by the heat exchanger in the water tank. 4.In case the temperature of the collector dose not reach the set valve, the circulation pump shall be shut automatically 5.In case the temperature of the water tank dose not reach T-max, then start the auxiliary heating device.



Heat Pipe Vacuum Tube Solar Collector

a.) Module design, arbitrary combination, harmonize with the building perfectly. b.) Intelligent control and automatic operation.

c.) Anti-freeze: using the anti-freezing liquid as the medium and the controller has the anti-freezing function.

d.) Multifunction: bathing, washing, domestic heating etc.

e.) Work at anytime and enjoyable.

f.) Material of model.



FAQ:

1- What is your Delivery Time?

LCL order:10days.

Full container order:15days.

2- What is your Guarantee Time?

6 years; Provide you with some accessories, they are free for you.

3- Can you accept OEM and ODM ?

YES, printing your LOGO on the product and package, it's free.

4- What is your payment term?

We accept T/T or L/C, Western Union and Paypal.

5-What is your MOQ?

4 sets

6-How do you pack?

LCL order in plywood case

Full container order in high quality export carton

7-What is your FOB port?

We accept FOB Shanghai, Ningbo, Shenzhen, Guanagzhou, Qingdao etc.

8-What is your monthly production capacity?

1000 sets

9-What is your shipping term?

By sea/Air/Rail/Truck

10-Do you any additional services?

YES!

We offer free spares according to your order quantity. Such as Vacuum Tube, tube holders, dusting rings, silicon rings, screws etc.

And we can offer logo design, Products Advertising Design etc services free.
