300L SS316 Inner Tank Pressurized Solar Water Heater Flat Plate Solar Collector

300L SS316 Inner Tank Pressurized Solar Water Heater Flat Plate Solar Collector
300L SS316 Inner Tank Pressurized Solar Water Heater Flat Plate Solar Collector 300L SS316 Inner Tank Pressurized Solar Water Heater Flat Plate Solar Collector 300L SS316 Inner Tank Pressurized Solar Water Heater Flat Plate Solar Collector

Large Image :  300L SS316 Inner Tank Pressurized Solar Water Heater Flat Plate Solar Collector

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 250L/300L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

300L SS316 Inner Tank Pressurized Solar Water Heater Flat Plate Solar Collector

Description
Capacity: 300L Structure: Integrated
Flat Plate: Blue Titanium Principle: Pressurized
Collector: Flat Plate Inner Tank: Stainless Steel 304/316
Bracket: Stainless Steel 201 0/20/30/45 Degrees Material: Copper Aluminum
High Light:

Blue Titanium Flat Plate Collector

,

SS316 Tank Flat Plate Solar Collector

,

Copper Aluminum Flat Plate Collector

300L SS316 Inner Tank Pressurized Solar Water Heater Flat Plate Solar Collector



Advantage:

Solar water heating is the conversion of sunlight into heat for water heating using a solar thermal collector,

Solar water heaters use the solar energy from the sun to generate heat (not electricity).

The solar water heating solution is used for shower, room heating, hotel, swimming pool etc.
• Combined with solar heation system, heat pump, electrical heater and other heating source.
• Use the Sun to Heat Your Water to save your energy costs.
• Heating element back-up.
• Optional coils to fast the efficiency of heat transferring.
• Optional water connections according to customers requests.
• High dencity polyurethane foam reduces heat loss and energy costs for maximum efficiency.



Flat Plate Solar Water Heater Features:

1. Using patent advanced coating technology with high efficiency performance.

2. High strength aluminum-alloy structure with surface varnish baking

3. High visual shape ,easy installation ,maintenance free

4. Pressurized designing ,operate with pressure up to 1 Mpa

5. Can be combined with existing energy source



Flat Plate Solar Collector Technical Data :



Model PT-F-AO PT-F-BC PT-F-BT
Data
Dimension LxWxH (mm) 2000*1000*80 / 2000*1250*80 / 2000*1500*80
Gross Area (m2 ) 2.00
Absorber Area (m2 ) 1.9
Number of covers 1
Cover Material Low iron tempered textured glass
Cover Thickness(mm) 3.2
Cover Transmission >91.7%
Weight (KGS) 29
Absorber
Absorber material Aluminium Plate
Absorber coating Anode Oxidation Black Chrome Blue Titanium
Welding Laser welding/Ultrasonic welding
Construction Type Grid type Grid type Grid type
Header Material Copper TP2 Copper TP2 Copper TP2
Header pipe Red copper/ Φ22*0.6*2 PCS
Riser Material Copper TP2/CA1220
Riser pipe Red copper/ Φ8*0.5*7 PCS/Φ10*0.5*7 PCS
Work Pressure 0.6Mpa
Test pressure 1.2Mpa
Thermal Insulation
Insulation Material Fiberglass
Insulation Thickness 40mm
Casing
Frame Aluminium alloy
Frame Colour Silver/Black
Back Plate Galvanized steel
Sealing Gasket EPDM



Flat Plate Solar Water Heater Technical Data :



Model PTP-BT-15 PTP-BT-20 PTP-BT-25 PTP-BT-30 PTP-BT-35
Water
Tank
Circulation Type Indirect/Closed circulation
Tank capacity 150L 200L 250L 300L 350L
Outer tank Color Steel Plate, 0.4mm Color: A - enamal white , B - silver
Inner tank Stainless steel SUS304-2B, 1.2mm
Working pressure 6 bar
Test pressure 12 bar
T/P valve 1 PC
Mag rod 1 PC
Electric booster 2KW 2KW 2KW 3KW 3KW
Flat Panel Solar Collector Dimension 2000 x 1000 x 80mm
Overall area 2m² x 1 PC 2m² x 2 PCS
Absorber material Aluminum Plate
Absorber coating Anode Oxidation / Black Chrome / Blue Titanium
Header pipe Red copper/ Φ22*0.6*2 PCS
Riser pipe Red copper/ Φ8*0.5*7 PCS/Φ10*0.5*7 PCS
Welding Laser welding/Ultrasonic welding
Cover material Low iron tempered textured glass
Frame material Anodised Aluminium Alloy
Insulation Glass Wool
Piping connector Φ22
Mounting Bracket Material Galvanized Steel Plate with plastic spraying, 1.4mm
Bracket style A: Flat roof (20° or 30° or 45°) B: Tilted roof ( 0° )



Packing:

LCL( Less than Container Load ): Carton and Wooden case

FCL( Full Container Load ):Carton



Delivery:

Usually, it is 10 Working days after receiving deposit or original L/C.
