100L 201 Stainless Steel Solar Water Heater 30tubes Low Pressure Solar Collector

100L 201 Stainless Steel Solar Water Heater 30tubes Low Pressure Solar Collector
100L 201 Stainless Steel Solar Water Heater 30tubes Low Pressure Solar Collector 100L 201 Stainless Steel Solar Water Heater 30tubes Low Pressure Solar Collector 100L 201 Stainless Steel Solar Water Heater 30tubes Low Pressure Solar Collector

Large Image :  100L 201 Stainless Steel Solar Water Heater 30tubes Low Pressure Solar Collector

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 200L 300L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T, D/P
Supply Ability: 5000units/month

100L 201 Stainless Steel Solar Water Heater 30tubes Low Pressure Solar Collector

Description
Capacity: 200L 300L Material: Food Grade
Inner Tank: Stainless Steel 316L Type: Non Pressurized
Outer Tank: Painted Steel Shell Tube: Vacuum Tube
Range Of Use: Bathing Bracket: Aluminum Alloy
High Light:

201 SS Low Pressure Solar Collector

,

100L Low Pressure Solar Collector

,

Aluminum Alloy Low Pressure Solar Collector

100L 201 Stainless Steel Solar Water Heater 30tubes Low Pressure Solar Collector



Specification:



1. Inner tank material: SUS304-2B food grade stainless steel 0.31mm

2. Outer tank material: stainless steel sheet 201, thickness 0.31mm,

3. Bracket:1.2mm SS 202 stainless steel sheet

4. Vacuum tube: 58mm diameter, 1800mm length,coated by AL-N-AL

5. Insulation layer: 50-65mm polyurethane foam

6. Hail resistance:25mm 7.Heat preservation:72hours



Working Principle:



This type use all-glasses evacuated tubes as the solar collector for absorbing sun energy and transferring

it into heat energy.

As the different densities of hot water and cold water, the hot water flows automatically upwards while the cold water flows down.

The water flowing cycle is created in the tube. And the water in the storage tank is heated from this natural circulation.

The hot water pressure of this non-pressure system is from the gravity, so it should be installed on the roof or at least 3-4 meters higher than hot water tap.

Or you can install a booster pump to get stronger outlet hot water.



Optional Accessories:



1. Booster Pump (adding the hot water out pressure)

2. Temperature Monitor(showing hot water temperature inside the main tank)

3. Electrical Heater (as back-up for cloudy or rainy day)



Storage Tank
Capacity 100Lt 150Lt 200Lt
Inner Tank Material Stainless Steel Stainless Steel Stainless Steel
Inner Tank Diameter 360mm 360mm 360mm
Insulation Material Polyurethane Polyurethane Polyurethane
Insulation Thickness 50mm 50mm 50mm
Insulation Density 36kg/m² 36kg/m² 36kg/m²
Outer Tank Material Colored Steel Colored Steel Colored Steel
Outer Tank Diameter 460mm 460mm 460mm



Frame
Material Powder-coating Zinc Powder-coating Zinc Powder-coating Zinc



Collector Tubes
Outer Tube Diameter 58mm 58mm 58mm
Material High Borosilicate glass High Borosilicate glass High Borosilicate glass
Tube NO. 12 15 20
Thickness 2.0-2.2mm 2.0-2.2mm 2.0-2.2mm
Inner Tube Diameter 47mm 47mm 47mm
Material High Borosilicate glass High Borosilicate glass High Borosilicate glass
Aperture Area m² 0.96m²(1.7mx0.047mx12) 1.2m²(1.7m*0.047m*15) 1.63m²(1.7m*0.047m*20)



Peformance
Q factor(System Output) 14.454(16MJ/m²) 16.090(16MJ/m²) 25.063(16MJ/m²)
Hail Test Hail Resistance/25mm Hail Resistance/25mm Hail Resistance/25mm
Freeze Test Freeze Resistance Freeze Resistance Freeze Resistance



Note:In order to allow for continuous improvement,Apollo Technology reserves the right to update and change specifications without prior notice



Additional Terms:



Payment Terms L/C, T/T
Minimum Order 2 sets
Lead Time / Delivery Time 15 Day(s)
Sample Available YES
Delivery Details after receipt of payment
Port of Lading Ningbo / Shanghai
Shipping by sea
Packing export carton
Target Market(s) Africa(except Middle East), Central & Southern Asia, Latin America, Southeast Asia
