Product Details:
|
| Capacity: | 200L | Structure: | Integrated |
|---|---|---|---|
| Principle: | High Pressure Pressurized | Accessories: | P/T Valve, Safety Valve, Magnesium Rod, Electrical Heater, Controller |
| Hail Resistance: | 25mm | Outer Tank: | Color Steel |
| Inner Tank: | Stainless Steel 316 | Heat Exchange: | Heat Pipe |
| High Light: | compact solar water heater,solar hot water heater |
||
200L Color Steel Integrated High Pressure Pressurized Heat Pipe Thermal Solar Water Heater
Description:
Food grade stainless inner tank with no-welding technology
Patented solar collector can produce hot water with even less than 3 hour exposure to sunlight
Patented insulation can guarantee your water hot for 72 hours without sun
Built-in electric heating element
Flexible location, easy to install
Maintenance free
High ROI: 1 to 3 year pay back time
Available sizes: 100L-36L (larger systems can also be created by linking systems together)
For both commercial and residential applications
Our solar water heaters use 3rd generation technology, maximizing efficiency up to 97%.
Water heating is currently one of the most cost-effective ways to utilize the power of the sun.
This diagram shows how the solar vacuum tubes capture energy from the sun and heat the cool water at the bottom of the storage tank.
Warm water naturally rises to the top of the tank and is then transferred through the pipe into your plumbing for use, combined with cold water at a mixing valve to control water temperature.
An optional Solar Tempering Valve can also be installed (recommended) on the solar water heater system to regulate the temperature of water coming from the tank.
| Product Model | Tubes | Tank Capacity | Absorbing Area | Weight | Dimension (L×W×H) |
Qty. per 20FT/40FT/40HQ |
| 470-1800/58-12 | 12pcs | 100L | 0.92m2 | 63KGS | 1830*1210*1600 | 52/ 104 / 126 |
| 470-1800/58-15 | 15pcs | 125L | 1.14m2 | 78KGS | 1830*1450*1600 | 43 / 86 / 104 |
| 470-1800/58-18 | 18pcs | 150L | 1.37m2 | 93KGS | 1830*1690*1600 | 35 / 70 / 85 |
| 470-1800/58-20 | 20pcs | 165L | 1.52m2 | 103KGS | 1830*1850*1600 | 32 / 64 / 78 |
| 470-1800/58-24 | 24pcs | 200L | 1.83m2 | 125KGS | 1830*2170*1600 | 27 / 55 / 67 |
| 470-1800/58-30 | 30pcs | 250L | 2.29m2 | 156KGS | 1830*2650*1600 | 23 / 46 / 55 |
No Electricity Required:
This is a pressurized system that has no pumps.
The water moves through the system from the pressure of the municipal water supply.
When you open your hot water faucet, hot water from the tank flows out and cold water flows into the tank to be reheated by the solar vacuum tubes.
No Over Heating:
These systems have a built in air release valve and Temperature and Pressure Valve that opens at 90 C or 194 F. Should the system get to hot it will simply vent off the excess heat.
Stainless Steel:
stainless steel inner tank with good anti-rust property.
OEM Service:
available.
Additional Information:
| Payment Terms | T/T |
| Minimum Order | 10 |
|
Lead Time / Delivery Time |
10 Day(s) |
| Sample Available | YES |
| Delivery Details | 15 days when we get your advanced payment |
| FOB Port | Ningbo,Shanghai |
| Loading Info | shipping |
| Packing Info | exported standard cartons |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
FAQ:
1. What is your Delivery Time?
LCL order:10days.
Full container order:15days.
2. What is your Guarantee Time?
6 years; Provide you with some accessories, they are free for you.
3. Can you accept OEM and ODM ?
YES, printing your LOGO on the product and package, it's free.
4. What is your payment term?
We accept T/T or L/C, Western Union and Paypal.
5. What is your MOQ?
4 sets
6. Low do you pack?
LCL order in plywood case
Full container order in high quality export carton
7. What is your FOB port?
We accept FOB Shanghai, Ningbo, Shenzhen, Guanagzhou, Qingdao etc.
8. What is your monthly production capacity?
1000 sets
9. What is your shipping term?
By sea/Air/Rail/Truck
10. Do you any additional services?
YES!
We offer free spares according to your order quantity. Such as Vacuum Tube, tube holders, dusting rings, silicon rings, screws etc.
And we can offer logo design, Products Advertising Design etc services free.
PDF Catalogue of High Pressure Pressurized Thermal Solar Water Heater.
