|Structure:||Integrated||Accessories:||P/T Valve, Safety Valve, Magnesium Rod, Electrical Heater, Controller|
|Principle:||High Pressure||Inner Tank:||Stainless Steel|
|Collector:||Heat Pipe||Heat Preservation:||3 Days|
Indirect Loop Pressurized Solar Water Heater,
Roof Mounted Solar High Pressure Geyser,
200L Pressurized Solar Water Heater
200L Pressurized Solar Water Heater Roof Mounted Solar Heating Collector
The pressurized water tank has no exhaust hole.
therefore, it must bear the pressure came from tap water and hot water.
When use, the hot water comes out because of water pressure.
Vacuum tube absorbs solar energy, and conductive copper pipe transfers the heat into the pressurized water tank.
In this case, the water inside the tank becomes hot.
No water in the heat pipe makes the whole system could bear pressure.
Inner tank: 1.2mm food grade SUS 304-2B stainless steel
Outer tank: 0.4mm galvanized steel
Evacuated/glass vacuum tube: Al/N/Al-SS-CC, 58 x 1800mm, 10 to 36 pieces
Heat pipe header: red copper
Frame: 1.5mm galvanized steel
Insulating material: 50 to 60mm polyurethane foam
Outer tank diameter: 460mm
Inter tank diameter: 360mm
Maximum working pressure: 6 bar
Heat preservation: 72 hours
Hail resistance: 25mm
Accessories: magnesium rod, electrical heater and P/T valve
Warranty: 6 years
Lead Time /
|Delivery Details||15 days when we get your advanced payment|
|Packing Info||exported standard cartons|
|Target Market(s)||Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe|
1. Electric heater:1500W-2000W/220V-230V;
2. Intelligent controller: SR609(esp. for integrative pressurized type);
3. P/T valve (pressure & temperature): WAY-20,0.7MPa;
4. Magnesium rod:diameter 20mm, length 23 cm, copper connector;
5. Temperature sensor;
6. Air vent valve;
7. Vacuum valve;
8. Check valve.
1. What is your Delivery Time?
Full container order:15days.
2. What is your Guarantee Time?
6 years; Provide you with some accessories, they are free for you.
3. Can you accept OEM and ODM ?
YES, printing your LOGO on the product and package, it's free.
4. What is your payment term?
We accept T/T or L/C, Western Union and Paypal.
5. What is your MOQ?
6. Low do you pack?
LCL order in plywood case
Full container order in high quality export carton
7. What is your FOB port?
We accept FOB Shanghai, Ningbo, Shenzhen, Guanagzhou, Qingdao etc.
8. What is your monthly production capacity?
9. What is your shipping term?
10. Do you any additional services?
We offer free spares according to your order quantity. Such as Vacuum Tube, tube holders, dusting rings, silicon rings, screws etc.
And we can offer logo design, Products Advertising Design etc services free.
PDF Catalogue of Integrative Pressurized Solar Water Heater.
