Split Pressurized Solar Water Heater Heat Pipe Collector for Large Capacity Solar Water Heating System for Hotel Resort

Split Pressurized Solar Water Heater Heat Pipe Collector for Large Capacity Solar Water Heating System for Hotel Resort

    • Split Pressurized Solar Water Heater Heat Pipe Collector for Large Capacity Solar Water Heating System for Hotel Resort
    • Split Pressurized Solar Water Heater Heat Pipe Collector for Large Capacity Solar Water Heating System for Hotel Resort
    • Split Pressurized Solar Water Heater Heat Pipe Collector for Large Capacity Solar Water Heating System for Hotel Resort
  • Split Pressurized Solar Water Heater Heat Pipe Collector for Large Capacity Solar Water Heating System for Hotel Resort

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 2000L/1500L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Capacity: 2000L/1500L Structure: Split System
    Flat Plate: Black Chrome Principle: Pressurized
    Collector: Flat Plate Inner Tank: Stainless Steel 304/316
    Bracket: Stainless Steel 201 0/20/30/45 Degrees Material: Copper Aluminum

    Split Pressurized Solar Water Heater Heat Pipe Collector for Large Capacity Solar Water Heating System for Hotel Resort



    Capacity:

    1000L/1500L/2000L/3000L/4000L/5000L.



    Flat Plate Solar Water Heater Description:

    Flat plate Solar Water Heater is one of common Solar Water Heater for solar water-heating system in homes and room heating.

    Flat plate Solar Water Heater provide quality hot water with its new solar energy efficient flat plate design.

    The flat plate solar collector includes a selective coating to maximize the solar heat absorption,

    aluminum framing and interior fiberglass insulation for increased efficiency.



    Advantage:

    1. Highly efficient absorber of high performance with daily average efficiency over 76%;
    2. Blue film absorber with automatic production line,can supply you stable high quality products;
    3. Withstand pressure of 6 Bar, can be connected directly with city water or your big water tank;
    4.Simple structure, easy to assembly and install in short time, no breakage;
    5.Best insulation with polyurethane foam;
    6.Can be used all year round in the cold climate;
    7.Can be used together with auxiliary electric boost;
    8.Long service life, can be used over 15 years;



    Flat Plate Solar Water Heater Features:

    1.Using patent advanced coating technology with high efficiency performance.

    2. High strength aluminum-alloy structure with surface varnish baking

    3. High visual shape ,easy installation ,maintenance free

    4. Pressurized designing, operate with pressure up to 1 Mpa

    5. Can be combined with existing energy source



    Heat Pipe Solar Collector Technical Data:



    Model PT-C-15 PT-C-18 PT-C-20 PT-C-24 PT-C-25 PT-C-30
    Tube QTY(PCS) 15 18 20 24 25 30
    Three Target Vacuum Tube Diameter/Length: φ58mm/1800mm; High boron and silicon content 3.3; Structure:Gradual change SS-AL-Nx/Cu selective absorption coating; Vacuum Degree:P<=5*10-3;
    Heat Pipe Condesor: φ14/φ24*70mm ; Thickness: 0.5mm ; Material: red copper TU1+water; Transfer Power:>=150W; Working Pressure:4Mpa; Welding Pressure:4Mpa;
    Outer Shell/Bracket Alluminum Alloy,Silver
    Insulation Layer Rock wool
    Dustproof Rubber EPDM
    Dsily Heat Gain 8.5MJ/m²
    Work Pressure 0.6MPa
    Inlet/outlet 22mm/3/4"
    Tailstock ABS
    Temperature 250 °С
    Contour Aperture Area 2.32m² 2.75m² 3.10m² 3.64m² 3.78m² 4.52m²
    Aperture Area 1.43m² 1.70m² 1.89m² 2.27m² 2.36m² 2.83m²
    Absorption Area 1.22m² 1.46m² 1.62m² 1.95m² 2.04m² 2.43m²



    Packing:

    LCL( Less than Container Load ):Wooden case

    FCL( Full Container Load ):Export carton



    Delivery:

    Usually, it is 10 Working days after receiving deposit or original L/C.



    Split Pressurized Solar Water Heater Heat Pipe Collector for Large Capacity Solar Water Heating System for Hotel Resort 0
