Integrated Pressurized Water Heater Copper Pipe Collector

Integrated Pressurized Water Heater Copper Pipe Collector
Integrated Pressurized Water Heater Copper Pipe Collector Integrated Pressurized Water Heater Copper Pipe Collector Integrated Pressurized Water Heater Copper Pipe Collector

Large Image :  Integrated Pressurized Water Heater Copper Pipe Collector

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 100L/150L/200L/250L/300L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

Integrated Pressurized Water Heater Copper Pipe Collector

Description
Capacity: 100L/150L/200L/250L/300L Structure: Integrated
Flat Plate: Blue Titanium Principle: Pressurized
Collector: Flat Plate Inner Tank: Stainless Steel 304/316
Bracket: Stainless Steel 201 0/20/30/45 Degrees Material: Copper Aluminum
High Light:

flat panel solar water heater

,

rooftop solar water heater

Integrated Blue Titanium Flat Plate Pressurized Water Heater Copper Pipe Collector



Flat Plate Solar Water Heater Features:

1.U sing patent advanced coating technology with high efficiency performance.

2. High strength aluminum-alloy structure with surface varnish baking

3. High visual shape ,easy installation ,maintenance free

4. Pressurized designing ,operate with pressure up to 1 Mpa

5. Can be combined with existing energy source



Advantage:

1. 16 years sale experience

2. Certificate:CE,ISO9001-2008,SRCC,Solar keymark,SGS,CCC

3. Life span:Approximate to 15 years

4. We can customize according to customers' requirement

5. Warranty time :6 years



Flat Plate Solar Water Heater Description:

Flat plate Solar Water Heater is one of common Solar Water Heater for solar water-heating system in homes and solar space heating.

Flat plate Solar Water Heater provide quality hot water with its new solar energy efficient flat plate design.This glazed collector includes a selective coating to maximize the solar heat absorption ,weather resistant aluminum framing and interior fiberglass insulation for increased efficiency



Packing:

LCL( Less than Container Load ):Wooden case

FCL( Full Container Load ):Export carton



Delivery:

Usually, it is 10 Working days after receiving deposit or original L/C.



Type Flat-Plate
Pressure Unpressurized
Circulation Type Direct / Open Loop (Active)
Heating System Batch/ICS(Passive)
Connection Type Direct-Plug
Installation Freestanding
Housing Material color steel
Certification CE, SRCC,ISO9001-2008, CCC, Solar keymark, SGS
Capacity 200
Place of Origin Zhejiang, China (Mainland)
Brand Name OEM
Model Number SC01
Heat preservation More than 72 hours
Warranty time 6 years



Flat Plate Solar Water Heater Technical Data :

Material Tempered textured glass
Cover thickness 4mm
Cover transmision 87%
Ext.Dimension 2000*1060*75/82/95mm
Aperture area 2 m²
Absorber
Dimension L*W*T 1840*980*0.15
Material Red copper
Surface coating Black chromed/blue sputtered
Construction type Fin&tube(ultrasonic welding)
Header mateial Copper T2
Header tube size(L*W*T) 1886mm*Φ10mm*0.458pcs
Absorptivity α=0.93(±0.05)
Emittance ξ=0.12(±0.02)
hermal insulation
insulation material Fibie glass Insulation(blacking backing)
insulation thickness Back 25mm
Conductivity(w/mk) ≤0.048w/m.k under test temperature 70°C
Other parameters
Bracket/Frame Aluminum alloy
Back plate Galvanized steel plate 0.3mm
Max operation temperature 200°C
Max pressure 1400kpa
sealing gasket EPDM
Max. working temperature 120°C
Max. working pressure 10bar
Daily output colume 105˜300L



FAQ:

- Can you provide FREE SAMPLES?

Sorry,you have to pay it first,but we'll cut the costs in your next order(20GP).

- Can you accept OED/ODM?

Yes,we can paint the logo on the product and package if you need,it is free for containers.

- What is your GUARANTEE TIME?

10 years for vacuum tubes,5 years for frame,3 years for water tank,1 year for other parts.

- What is your PAYMENT TERM?

T/T , L/C

- Do you have other ADDITIONAL SERVICE?

YES.

We provide free spares according to your order, such as vacuum tubes,tube holders,dust rings,

seal rings,screws etc.

Also,we can provide logo design free if you have an order at least 20 feet container.
