300L Thermal Flat Plate Collectors Solar Water Heating System 304 Inner Tank Blue Film

300L Thermal Flat Plate Collectors Solar Water Heating System 304 Inner Tank Blue Film
300L Thermal Flat Plate Collectors Solar Water Heating System 304 Inner Tank Blue Film 300L Thermal Flat Plate Collectors Solar Water Heating System 304 Inner Tank Blue Film 300L Thermal Flat Plate Collectors Solar Water Heating System 304 Inner Tank Blue Film

Large Image :  300L Thermal Flat Plate Collectors Solar Water Heating System 304 Inner Tank Blue Film

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 300L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

300L Thermal Flat Plate Collectors Solar Water Heating System 304 Inner Tank Blue Film

Description
Capacity: 300L Working Pressure: 6 Bar
Insulation: 55mm High Pressure Polyurethane Foam Flat Panel: Black Chrome
Collector: Flat Plate Outer Tank: Stainless Steel
Inner Tank: Stainless Steel Bracket: Stainless Steel 304 0/20/30/45 Degrees
High Light:

flat panel solar water heater

,

rooftop solar water heater

300L Thermal Flat Plate Collectors Solar Water Heating System 304 Inner Tank Blue Film



Specifications:

Tank

Inner tank: SUS 304 /2B x Φ550mm

Insulation: polyurethane

Outer tank: Color steel

Max operating pressure: 10 bar

Out/inlet: G 3/4"



Features:
1. Stylish streamline design for the solar water heater
2. Reliable electric booster with thermal cut-out for for water tank
3. Thermosiphon circulation with less maintenance for the solar system
4. The inner tank coated with vitreous enamel for long life
5. High-efficient solar collector for optimum heat absorbtion
6. The solar water heater system have passed EN12975-1, 2, ISO9806-2 test.
7. The solar water heater are solar keymark certificated.
8. The solar water heater are CE certificated.



Solar collector Model No. PT-F-BT
Absorber Material Black chrome coating,all copper absorber
Dimension LxWxT 2000*1000*95mm
Overall area 2m 2 X1pcs
Absorption 95%
Emittance ≤11%
Water Tank Circulation Type Pressurized open loop
Tank capacity 150L
External dimension Ø525x1300mm
Outer tank material Aluzinc Steel
Inner tank material Low carbon steel with vitreous enamel
Max working pressure 0.6 Mpa
Eelctric booster 1.5kw
Mounting rack Material Galvanized steel
Bracket style A: flat roof or B:Sloping roof
Circulation Piping Material Stainless steel corrugated pipe
Connector and fittings Plug with electricity leakage protection*1pcs 10A,3meter(plug type will be choosen according to the different country)
One way*1pcs Copper, 1”
T/P valve*1pcs Copper,G3/4",99C,0.6Mpa
3 way*2pcs SUS304,G3/4",female
Copper block bar*2pcs Copper,φ22
Controller Intelligent controller
Overall weight Weight of overall system(empty)(kg) 125
Weight of overall system(filled)(kg) 275
Container loading 20' 36sets(flat roof) 30sets(sloping roof)
40' 72sets(flat roof) 60sets(sloping roof)



Flat plate solar collector:

Size: 2000 x 1000 x 82.5 mm or 1500 x 1000 x 82.5 mm

Total surface area: 2 sq.metre / 1.5 sq.metre

Max. Temp: 200 degree Celsius

Working operating pressure: 10 bar

Recommended mounting angle: 10-90 degree

Manifold 22 mm O.D - Risers 10 mm O.D

Plumbing connections: 22 mm

Frame anodized aluminium: corrosion resistant

Absorber: selective black anodized

Thermal insulation: Glass wool

Absorptivity/ emissivity: 97% / 20%

Light transmission ≥ 89% ( solar tempered textured glass)

Suitable for pitched and flat roof installation

Package way: carton / pc

10 Year Limited Warranty



Packing:

LCL( Less than Container Load ):Wooden case

FCL( Full Container Load ):Export carton



Delivery:

Usually, it is 10 Working days after receiving deposit or original L/C.



FAQ:

- Can you provide FREE SAMPLES?

Sorry,you have to pay it first,but we'll cut the costs in your next order(20GP).

- Can you accept OED/ODM?

Yes,we can paint the logo on the product and package if you need,it is free for containers.

- What is your GUARANTEE TIME?

10 years for vacuum tubes,5 years for frame,3 years for water tank,1 year for other parts.

- What is your PAYMENT TERM?

T/T , L/C

-

Do you have other ADDITIONAL SERVICE?

YES.

We provide free spares according to your order, such as vacuum tubes,tube holders,dust rings,

seal rings,screws etc.

Also,we can provide logo design free if you have an order at least 20 feet container.
