|Structure:||Split||Accessories:||P/T Valve, Safety Valve, Magnesium Rod, Electrical Heater, Controller|
|Outer Tank:||Painted Steel||Inner Tank:||Stainless Steel 304|
|Bracket:||Aluminum 0/20/30/45 Degrees||Heat Preservation:||72 Hours|
residential solar water heater,
split pressurized solar water heater,
Closed Loop Split Solar Water Heater
300L Closed Loop Solar Water Heater For Sewage Purification Environmental Protection
|ART.NO.||TUBE SIZE||QTY OF TUBES||TANK CAPACITY||PEOPLE NO.||CBM|
We have 8 senior engineers working on development. that will make us lead the trend whatever on structure or technology.
15 QC control the quality, just make sure all is right.
Aftersale service is quick, any problem you mentioned will be dealt with in 24 hours.
Our professional salesmen always online for your questions.
Vacuum tube: D58-L1800MM, CU/SS-AL/N heat pipe vacuum tube
Outer manifold material: Aluminum alloy/galvernized steel
Frame:Galvanized steel with plastic spraying/Aluminum alloy,thickness:1.2-2mm
Reflector: Stainless steel/Aluminum alloy as option
Inner tank: Imported SUS304-2B food-level stainless steel,thickness: 1.5~2.5MM
Outer tank: High quality color steel,thickness: 0.45~0.5MM
Tank cover thickness: 0.5MM
Insulation layer: 50~100MM polyurethane foam
Density of tank insulation layer: 35kg/m3
Rated working pressure: 0.7Mpa
Attachments: Power controlling box,electric heater,Magnesium bar,P/T valve,pressure reducing valve
Expansion case,check valve,circulation pump,solar controller,pressure gauge,safety valve,flow meter, below 250L matched 5L expansion case, above 250L matched 8L.
L/C at sight
30% T/T in advance as deposit, the rest paid before shipment
30% T/T in advance as deposit, the rest paid against B/L copy
Evacuated Tube Solar Water Heater: standard export package.
The samples are loaded into the plywood boxes.
1) The angle of the frame can be changed in production according to the local latitude condition of the customers. We can design the suitable angle for the customers
2) We offer the spare accessories and tubes for your order for free
3) We can offer the standing frame for SFB if the customers need
4) We can change the quantity of tubes of each SFB solar collector according to customers' request
5) We can change the different material of manifold according to the requirement of customers , SFB with standing frame.
PDF catalogue of Split Pressurized Solar Water Heater.
