Convenient Install Heat Pipe Solar Collector With Reflectors 24mm Condenser

Convenient Install Heat Pipe Solar Collector With Reflectors 24mm Condenser
Convenient Install Heat Pipe Solar Collector With Reflectors 24mm Condenser Convenient Install Heat Pipe Solar Collector With Reflectors 24mm Condenser

Large Image :  Convenient Install Heat Pipe Solar Collector With Reflectors 24mm Condenser

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 20tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

Convenient Install Heat Pipe Solar Collector With Reflectors 24mm Condenser

Description
Collector Tubes: 20 Tubes Insulation: Rock Wool
Bracket: Aluminum Alloy Assembly: Flat Roof
Heat Pipe: 24mm Condenser Manifold Color: Silver
Angle Of Bracket: 30 Degree Application: Apartment
High Light:

pressurized solar collector

,

solar hot water collector

High Efficiency Heat Pipe Solar Collector 10-30 Tubes With Reflectors 24mm Condenser


Description


1) solar collector is designed with pressure up to 0.6Mpa.
2) Easy to use, also convenient to install
3) Can be put in the courtyard, on the roof or balcony
4) Inlet water hole connects to the tap water, and the outlet hole connects to the tap water, and the outlet hole produces pressure hot water directly
5)Efficiency: The advantage of solar tubes is that insulate the inner tube from heat loss. This means that once heat is absorbed, it is transferred to the water in the manifold, and not lost to the outside environment.

6)Aesthetics: Solar collector is designed to be low profile, sitting closed to the surface of the roof. Tubes are black and so blend in nicely with most roof colors.
7) Heat pipe has its special principle and function, and no water in the pipe. If one of the pipe is broken, the heat collector still could be used normally. Therefore, this kind of products has gradually accepted by consumers.



Features:



1) Reliable & efficient twin-glass solar tubes

2) Copper heat pipes for rapid heat transfer

3) Easy plug-in installation

4) Free maintenance

5) Suitable for mains pressure water

6) Corrosion resistant silver brazed copper header

7) The surface is made of powder coated galvanized steel

8) Stable solar conversion during the day

9) The perfect solar collector for domestic solar water heater systems

10) Ideal for commercial solar water heating applications



Principle



1) The operation of the solar collector is very simple

2) Solar absorption: solar radiation is absorbed by the solar tubes &converted into heat

3) Solar heat transfer: heat pipes conduct the heat from within the solar tube up to the heater pipe

4) Solar energy storage: water is circulated through the header, Via intermittent pump cycling. Each time the water circulates through the header, the temperatures is raised by 5-10°C.

The water in the tank is gradually heated time by time.



Model Absorbing Area(m2) Heat pipe vacuum tube Water Temperature (Centigrade)

Loading Qty(sets)

20"/40"

Ø(mm) L(mm) NO.(PCS)
PT-47/1500-12 1.2 47 1500 70 60 141/295
PT-47/1500-15 1.5 47 1500 70 60 120/270
PT-47/1500-18 1.8 47 1500 120 60 95/198
PT-47/1500-20 2.0 47 1500 120 60 85/178
PT-47/1500-24 2.4 47 1500 150 60 71/148
PT-47/1500-30 3.0 47 1500 180 60 57/120
PT-58/1800-12 1.99 58 1800 110 60 123/258
PT-58/1800-18 2.66 58 1800 150 60 85/172
PT-58/1800-20 2.98 58 1800 175 60 73/155
PT-58/1800-24 3.56 58 1800 220 60 56/118
PT-58/1800-30 4.43 58 1800 260 60 45/96



Tips



· Considering the economics of a solar water heating system

· Evaluate your site's solar resource

· Determine the correct system size

· Determine the system's energy efficiency



Warranty & Service



Warranty: 6 years

If some problem happens which is relative to our quality, we are absolutely responsible for it.

Contact with us at anytime, we will solve it in time.
