18 Tubes Copper Heat Pipe Solar Collector

18 Tubes Copper Heat Pipe Solar Collector
18 Tubes Copper Heat Pipe Solar Collector 18 Tubes Copper Heat Pipe Solar Collector 18 Tubes Copper Heat Pipe Solar Collector 18 Tubes Copper Heat Pipe Solar Collector

Large Image :  18 Tubes Copper Heat Pipe Solar Collector

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 18tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

18 Tubes Copper Heat Pipe Solar Collector

Description
Collector Tubes: 18 Tubes Insulation: Glass Wool
Housing Material: Oxide Aluminum Alloy Assembly: Pitched Roof
Heat Pipe: 14*70mm Condenser Copper Manifold Color: Silver
Reflector: Stainless Steel Application: Heating Water Tank
High Light:

heat pipe vacuum tube solar collector

,

solar hot water collector

Energy Saving 18 Tubes Copper Heat Pipe Solar Collector Stainless Steel Reflector



How the heat pipe collector works:



Step 1: Sunlight is absorbed inside the evacuated tube causing it to heat up.

Step 2: The heat pipe inside the tube carries this thermal energy up to the manifold box.

Step 3: Fluid circulates from the storage tank up through to the header pipe and extracts the energy from the hot heat pipe tips.

Step 4: The newly heated fluid circulates back to the storage tank where it can be used and the cycle begins again.



Application:



The solar collector can be installed in solar heating system to heat water for wide variety of uses, including home, hotel, school, business project and industrial uses. When in series or parallel connection, it also can be used to heat swimming pools, and supply heat for under floor heating.



Feature:

1.No water flows in the evacuated tubes, so water scale and tube exposition are avoided, Single broken tube will not affect the working of the system.

2.No freezing problem in winter – can be used in cold area.

3.It can be integrated with architecture perfectly and be connected with existing pipes.

4.High performance evacuated tube collectors.

5.Ideal for industrial application wherein high temperature requirement.

6.Can be mounted free-standing or on a pitched roof , easy to install, simple roof fixing.

7.Heat pipe – offer low maintenance

8.Triple layer selective absorber coating, absorption > 94%

9.Aluminum frame – Strong structure, light weight.



Parameter List
Model Heat Pipe Solar Collector
Numbers of Tubes 8,12,14,15,18,20,24,30,36
Dimension & Testing Data
Outer Manifold 2.0MM Alloy Aluminum
Inner Pipe 0.8MM Thickness,35MM DI for inside,and 22MM DI for outer connection part.
Frame 2.0MM Alloy Aluminum
Heat Pipe Tube

Copper Pipe:0.6MM Thickness with 1700MM Length,8MM DI for body part,and 14MM for head part.

Vacuum Tube:58*1800 3T vacuum tube

Aluminum Fin:0.15mm thick sets of Aluminum fins,1600mm

Insulation Material Rock Wool
Working/Testing pressure 6 bar/12 bar
Max Testing Pressure 12 bar
Stagnation Temperature 236°C
Packing Dimension & Weight
Heat Pipe & Frame Package (Tube QTY-1)*hole distance+210mm}*200mm*180mm
Tubes Packing 1940*340*170mm
Certificates CCC,ISO9001,CE
Tube Holder/ Seals Silicon seal



Notes:



1.The goods are on the basis of FOB Shanghai terms or CIF.

2.Term of the payment: 100%T/T in advance for LCL.

30% T/T in advance,balance 70% after the receipting the copy of the B/L.

3.Delivery time is 15 days for full container.

4.Package:all goods are in cartons for full container ,samples will be in plywood case.

5.MOQ:Negotiation.



Packaging & Delivery



Packaging Details:

1. Standard export packing for FCL order.
2. Special packing for LCL order.



Delivery Detail:

10-15 days after receipt of deposit.



FAQ

1- What is your Delivery Time?

LCL order/Sample order: 3--7days.

Full container order:7-10days.

2- What is your Guarantee Time?

3 years.

3- Can you accept OEM ?

YES, will do OEM Basing on all your detailed requirements.

4- What is your Payment Term?

We accept T/T,Escrow & West Union

5-What is your MOQ?

1 set

6-What is your Packing?

LCL order/Sample order in wooden box Package

Full container order in Standard quality export carton with PE Foam Protection

7-What is your FOB Port?

We accept FOB Shanghai & Ningbo

8.-What is your Monthly Production Capacity?

1000 sets

9-What is your Shipping Term?

By Sea/Air/Rail
