304 Mirror Non Pressurized Solar Water Heater Vacuum Tube With 200Liter Tank

304 Mirror Non Pressurized Solar Water Heater Vacuum Tube With 200Liter Tank
304 Mirror Non Pressurized Solar Water Heater Vacuum Tube With 200Liter Tank 304 Mirror Non Pressurized Solar Water Heater Vacuum Tube With 200Liter Tank 304 Mirror Non Pressurized Solar Water Heater Vacuum Tube With 200Liter Tank 304 Mirror Non Pressurized Solar Water Heater Vacuum Tube With 200Liter Tank

Large Image :  304 Mirror Non Pressurized Solar Water Heater Vacuum Tube With 200Liter Tank

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 200L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T, D/P
Supply Ability: 5000units/month

304 Mirror Non Pressurized Solar Water Heater Vacuum Tube With 200Liter Tank

Description
Capacity: 200L Working Pressure: 0.5 Bar
Insulation: 55mm High Pressure Polyurethane Foam Type: Non Pressurized
Tube: Vacuum Tube Outer Tank: 304 Mirror
Inner Tank: Stainless Steel Bracket: Stainless Steel 304 0/20/30/45 Degrees
High Light:

evacuated tube solar hot water heater

,

solar roof water heater

304 Mirror Gravity-fed Non Pressurized Vacuum Tube Solar Water Heater with 200Liter Tank



Working principle:



The series employs the natural convection phenomenon called “thermosyphon”.

The evacuated tubes convert solar energy into heat energy and transfers heat to water.

The lighter hot water in tubes rises to the storage tank, while the cold water at the bottom of the tank flows into the tubes, creating continuous circulation.

The convection flow will continue as long as the sun is heating the collector.



Specifications:



Thermosyphon solar water heater with CE certificate, strong frame, golden color shape,

Integrative thermosyphon solar heating system is a low pressure solar water heater which provides basic hot water demand.

This system relies on the natural circulation of water between the collector and the tank.

As water in the vacuum tubes is heated it rises naturally into the tank, while cold water in the tank flows down to the bottom of the vacuum tubes, causing circulation throughout the system.



Features:



1. It is non-pressurized thermosyphon solar water heater with water tank, and is economical as a natural circulation system.
2. The material of inner tank is SUS304 2B food grade stainless steel with 0.4mm thickness.
3. The material of outer tank is SUS304 stainless steel with 0.4mm thickness.
4. The material of stand frame is stainless steel with 1.2mm thickness. The angle of the frame can be changed in the production as the local latitude of customers, we can design the suitable angle for the customers. We also could provide the adjustable frame.
5. The thickness of polyurethane foam is 55-60mm.
6. It uses vacuum tubes, the water could be heated in the tubes directly.
7. It is very popular in torrid zone and warm area, such as Asia, Africa and etc.
8. The installation and maintain is very easy.
9.  We offer the accessories of this system, such as electric heater, assistant tank, controller, magnesium and etc.

10. Capacity from 50L to 500L

11. Passed EN12976 standard testing in Europe



Tube QTY Tube size Water Capacity(L) Supply ability QTY in 20GP/40HQ
10 58*1800mm 100L 1--2 people 68/165
15 58*1800mm 150L 2--3 people 53/128
20 58*1800mm 200L 3--4 people 40/97
24 58*1800mm 240L 4--5 people 34/82
30 58*1800mm 300L 5--6 people 28/68
36 58*1800mm 360L 6--7 people 24/57
42 58*1800mm 420L 7--8 people 20/50



Optional Accessories:



Assistant tank (5L/8L/12L)

Intelligent controller

Electric backup Heating element



Payment Terms L/C, T/T
Minimum Order 2 sets
Lead Time / Delivery Time 15 Day(s)
Sample Available YES
Delivery Details after receipt of payment
Port of Lading Ningbo / Shanghai
Shipping by sea
Packing export carton
Target Market(s) Africa(except Middle East), Central & Southern Asia, Latin America, Southeast Asia
