5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating

5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating
5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating 5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating 5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating

Large Image :  5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 50 Tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T, D/P
Supply Ability: 5000units/month

5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating

Description
Model: 50Tubes/5000L Working Pressure: 0.5 Bar
Insulation: High Pressure Polyurethane Foam Evacuated Tube: Al/N/Al-SS-CC, Triple Element
Use: Project Solution Manifold: Stainless Steel
Inner Tank: Stainless Steel 316L Bracket: Stainless Steel 201 0/20/30/45 Degrees
High Light:

5000L Centralized Solar Water Heater

,

Vacuum Tube Solar Collector 5000L

,

0.5 Bar Solar Water Heater

5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating



Solar Water Heating System



It is professional in central hot water supply of hotel, school, hospital, residence etc.



Features



1. Especially for large-scale hot water heating system, supplying hot water for apartments, hotels, restaurants, schools, hospitals, factories, swimming pools, and other places requiring large amount hot water use.

2. Very economical and of good performance for a 15 years lifespan

3. Adaptable to different architecture structure installation

4. Anti-freezing system with good insulation to the pipelines

5. Easy installation and connection of solar collectors and pipelines

6. Able to be designed to work with auxiliary heating devices to assist solar water heating



Advantage


1) Strong adaptability
2) Wide application occasions
3) High degree of automation
4) Economical and practical
5) Environmental conservation and energy
6) In large-scale projects, auxiliary heating system, computerized controller and pipe cycling system
7) According to the required configuration, it can be divided into two types. One is vertical and the other is horizontal
8) with large heat collecting capacity



Applications


1) Hotels, resorts, hospitals and hostels
2) Process industry, boiler feed, laundry and canteens
3) Agricultural sector, hatcheries and dairies
4) Process industry, Boiler feed, Laundry and canteens
5) Agricultural sector, hatcheries, and dairies
6) Swimming pool heating
7) In-process heating
8) Health clubs (Steam / Sauna)



Specifications



Modle PT-NC-15 PT-NC-20 PT-NC-25 PT-NC-30 PT-NC-40 PT-NC-50 PT-NC-60
Quantity of Tubes 15 20 25 30 40 50 60
Contour aperture area 1.94m2 2.58m2 3.22m2 3.88m2 5.16m2 6.44m2 7.76m2
Manifold Inner shell: 304 2B Foaming: High pressure polyurethane
Three Target Vacuum Tube Diameter/Length: φ58mm/1800mm; High boron and silicon content 3.3; Structure:Gradual change SS-AL-Nx/Cu selective absorption coating; Vacuum Degree:P<=5*10-3;
Anti-dust Ring White Silicon Rubber
Work Pressure 0.05Mpa
Bracket Galvanized Steel with Plastic Coating in Black color - 0/20/30/45 degrees
Tailstock ABS
OEM Service Logo painting on products and package is for free (20FT,40FT,40HQ)



Warranty:



6 years international responsibility for U pipe solar collector and 15 years for vacuum tubes due to original quality problems.



Payment term:

1. T/T 30% Deposit in advance and balance should be paid after receiving the B/L copy.

2. L/C at sight (if your quantity reaches 5*40’ HQ container)

3. Sample order or LCL: we accept western union and one touch business.



Packaging & Delivery

Packaging Details:

Export carton for full container.

Delivery Detail:

7 days after receiving the deposit.

5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating 05000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating 1

5000L Centralized Solar Water Heater Non Pressure Vacuum Tube Solar Collector Heating 2

PDF Catalogue of Non Pressure Solar Collector.



PT-NC Non Pressure Solar Collector.pdf
