2000L Non Pressure Solar Water Heater Hotel Vacuum Tube Solar Heating Collector

2000L Non Pressure Solar Water Heater Hotel Vacuum Tube Solar Heating Collector
2000L Non Pressure Solar Water Heater Hotel Vacuum Tube Solar Heating Collector 2000L Non Pressure Solar Water Heater Hotel Vacuum Tube Solar Heating Collector 2000L Non Pressure Solar Water Heater Hotel Vacuum Tube Solar Heating Collector

Large Image :  2000L Non Pressure Solar Water Heater Hotel Vacuum Tube Solar Heating Collector

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 2000L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T, D/P
Supply Ability: 5000units/month

2000L Non Pressure Solar Water Heater Hotel Vacuum Tube Solar Heating Collector

Description
Capacity: 1000L Tubes: Glass Tubular
Collector: Vacuum Tube Accessories: Feeding Tank
Outer Tank: Stainless Steel Inner Tank: Stainless Steel 316
Bracket: Stainless Steel 201 0/20/30/45 Degrees Heat Preservation: 72 Hours
High Light:

2000L Non Pressure Water Heater

,

Glass Tubular Non Pressure Water Heater

,

SS316 Non Pressure Water Heater

2000L Non Pressure Solar Water Heater Hotel Vacuum Tube Solar Heating Collector



Specifications

Stainless steel, multi-angle
14 year factory, export quality
10 days to deliver 1 container
Warranty 10 years for system



Feature



1. Its specially suitable and widely used in large capacity solar water heating project, such as swimming pool, hotel, school, house, restaurant, farm etc.

2. It is the most economical solution for solar water heating project. Cost of vacuum tube solar collector is much lower (around 50% less) than heat pipe (pressurized) solar collector.

3. It can operate automatically, remote controlling.

4. Any type of back up heating can be combined

5. Easy installation and connection and little maintenance needed.

Non-pressure solar collector application


1. Hotels, resorts, hospitals and hostels
2. Process industry, boiler feed, laundry and canteens
3. Agricultural sector, hatcheries and dairies
4. Process industry, Boiler feed, Laundry and canteens
5. Agricultural sector, hatcheries, and dairies
6. Swimming pool heating
7. In-process heating
8. Health clubs (Steam / Sauna)



Technical data



Vacuum Tube borosilicate glass 3.3
Tube Coating Three layers coating, tri target tube
Tube Dimension 58mm*1800mm
Manifold inner material SUS304-2Bstailess steel
Manifold outer material Aluminum alloy
Bracket Aluminum alloy or stainless steel
Insulation Foam 40mm polyurethane foam
Number of Tubes 20, 30, 40, 50



Description Non-pressure solar collector
Material of inner tank 0.4mm thickness SUS304/2B Food grade stainless steel
Material of manifold tank 0.4mm thickness SUS304/BA stainless steel
Tank insulating layer 40mm 50kg/m³ high-density polyurethane foam
Inlet and outlet hole Male G 1’ /NPT1'
Solar collector tube 3.3 Borosilicate glass with ALN coating
Thickness of glass tube 1.6mm
Vacuum tube tightness P≤0.005 Pa
Absorption as=0.93-0.96(AM1.5)
Emission ratio εh=0.04-0.06(80C±5C)
Idle sunning property parameters Y=220~260m2.C/KW
Average heat loss coefficient ULT=0.6~0.7W/(m2.C)
Bracket: Aluminium alloy with anti-corrosion treatment, 1.8mm thickness
Frame angle:

15°/25°/27°/30°/35°/45°/52°

<Please select specific angle when you order>

Welding: Argon arc welding, spot welding
Fastening pieces: Made of stainless steel screw
Frame angle: Nylon bottom support, silicon gasket
Max working temp.: 99°C
Max pressure: 0.005Mpa
Hail resistance: Ø25mm
Anti Freezing: -20°C
Wind resistance: 20m/s
Instruction manual: Available
