|Frame Colour:||Black||Pipe Material:||TP Copper|
|Cover Material:||Low Iron Tempered Textured Glass||Insulation Material:||Fiberglass|
|Frame:||Anodised Aluminium Alloy||Dimension LxWxH (mm):||2000*1000*80|
|Absorber:||Blue Film Coating||Welding:||Ultrasonic Welding|
flat panel solar collector,
solar panel collector
Ultrasonic Welding high efficiency flat plate solar thermal collector for project
Blue titanium Flat solar collector specification.
1. Copper pipes and fins
2. Blue Titanium Coating
3. American ultrasonic welding
4. Tempered glass cover
5. Size: 2000*1000*80mm
1. Great pressurization property, very safe and clean.
2. Absorption ≥94%; emission ≤10%.
3. Strong thermal stability.
4. Strong welding property and conductivity.
5. Long using lifespan, lower maintain fee.
6. Convenient to solve the problem of overheating system in non-heating season.
Durable and corrosion-resistant material makes your maintenance cost low.
Comfortable hot water can be gained even in medium solar radiation areas.
Increases the value of your property.
Long lifespan to 25 years, makes your investment more worth it.
Worry-free from hails or other terrible weathers.
|Type||Blue Film Solar Panel|
|Material of the frame||Aluminum alloy|
|Gross area||2.00 M^2|
|Absorber surface||0.2mm copper sheet with Blue selective coating by vacuum magnetic controlling sputtering tec.Imported from Germany|
|Total weight of collector||36 KGS|
|Back plate||Galvanized steel plate 0.40mm|
|Cover sheet material||Low iron glass tempered 3.2mm|
|Insulation||Back:35mm ; Side:25mm; Fiber glass|
|Header connection size||22mm*0.6mm(2pcs)|
|Riser tube size||10mm * 0.5mm (7 pcs)|
|Life span||35 years|
Packaging & Shipping
Packaging Details: Export strong corrugated carton.
Delivery Detail: Within 7 - 10 days for container order quantity upon confirmed invoice or sales contract.
10 years international responsibility for Flat Plate Panel Solar Collector due to original quality problems.
1. We accept sample order for testing our quality.
For customer's sample requirements, usually we are requiring them to pay the sample cost and
Considering the extra labor cost, usually the sample charge will be 10~20% higher than our offer.
This sample charge is for the first deal only and will be deducted in your future formal orders.
2. For our regular customers, all the samples are free of charge.
3. Sample lead time:
according to the sample inventory situation, 5-10 working days after receipt of sample charges.
4. We can supply customer1-2pcs sample for checking the quality.
If more quantity,it will be problems for us, since my company do not keep many stocks.
So for the sample order quantity more than 2pcs, customers have to wait for a longer time.
Basic trade term & packages
MOQ: 20'GP container (Sample is available)
Warranty: 10 years guarantee for whole set solar water heater
Payment term: 30% deposit by TT, Balance for BL by TT or LC
Delivery time: 7-15 days after confirmed
Port of departure: Shanghai or Ningbo
Supply ability: 8000 sets per month
Package: Standard export cartons
Our service for you
We have flat plate solar collector factory,vacuum tubes factory and water tank factory for more than 10 years.
We provide 10 years warranty for the whole system. Others normally are 5 years only.
Keep the delivery time exact.
Your inquiry will be replied within 12 hours.
We offer you professional service with fluent English.
Keep the bulk production as the samples in high quality.
Freight forwarder: faster, safer and convenient.
Quality : we have QC in each process.
