Solar Water Heater Vacuum Tube Solar Collector , Evacuated Tube Collector

Solar Water Heater Vacuum Tube Solar Collector , Evacuated Tube Collector

    • Solar Water Heater Vacuum Tube Solar Collector , Evacuated Tube Collector
    • Solar Water Heater Vacuum Tube Solar Collector , Evacuated Tube Collector
    • Solar Water Heater Vacuum Tube Solar Collector , Evacuated Tube Collector
  • Solar Water Heater Vacuum Tube Solar Collector , Evacuated Tube Collector

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 1000L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T, D/P
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Capacity: 1000L Tubes: Glass Tubular
    Collector: Vacuum Tube Accessories: Feeding Tank
    Outer Tank: Stainless Steel Inner Tank: Stainless Steel 316
    Bracket: Stainless Steel 201 0/20/30/45 Degrees Heat Preservation: 72 Hours
    High Light:

    vacuum tube hot water solar collector

    ,

    solar evacuated tube collectors



    Solar Water Heater Vacuum Tube Solar Collector , Evacuated Tube Collector



    Specifications

    Stainless steel, multi-angle
    14 year factory, export quality
    10 days to deliver 1 container
    Warranty 10 years for system



    Feature



    1. Its specially suitable and widely used in large capacity solar water heating project, such as swimming pool, hotel, school, house, restaurant, farm etc.

    2. It is the most economical solution for solar water heating project. Cost of vacuum tube solar collector is much lower (around 50% less) than heat pipe (pressurized) solar collector.

    3. It can operate automatically, remote controlling.

    4. Any type of back up heating can be combined

    5. Easy installation and connection and little maintenance needed.

    Non-pressure solar collector application


    1. Hotels, resorts, hospitals and hostels
    2. Process industry, boiler feed, laundry and canteens
    3. Agricultural sector, hatcheries and dairies
    4. Process industry, Boiler feed, Laundry and canteens
    5. Agricultural sector, hatcheries, and dairies
    6. Swimming pool heating
    7. In-process heating
    8. Health clubs (Steam / Sauna)



    Technical data



    Vacuum Tube borosilicate glass 3.3
    Tube Coating Three layers coating, tri target tube
    Tube Dimension 58mm*1800mm
    Manifold inner material SUS304-2Bstailess steel
    Manifold outer material Aluminum alloy
    Bracket Aluminum alloy or stainless steel
    Insulation Foam 40mm polyurethane foam
    Number of Tubes 20, 30, 40, 50



    Description Non-pressure solar collector
    Material of inner tank 0.4mm thickness SUS304/2B Food grade stainless steel
    Material of manifold tank 0.4mm thickness SUS304/BA stainless steel
    Tank insulating layer 40mm 50kg/m³ high-density polyurethane foam
    Inlet and outlet hole Male G 1’ /NPT1'
    Solar collector tube 3.3 Borosilicate glass with ALN coating
    Thickness of glass tube 1.6mm
    Vacuum tube tightness P≤0.005 Pa
    Absorption as=0.93-0.96(AM1.5)
    Emission ratio εh=0.04-0.06(80C±5C)
    Idle sunning property parameters Y=220~260m2.C/KW
    Average heat loss coefficient ULT=0.6~0.7W/(m2.C)
    Bracket: Aluminium alloy with anti-corrosion treatment, 1.8mm thickness
    Frame angle:

    15°/25°/27°/30°/35°/45°/52°

    <Please select specific angle when you order>

    Welding: Argon arc welding, spot welding
    Fastening pieces: Made of stainless steel screw
    Frame angle: Nylon bottom support, silicon gasket
    Max working temp.: 99°C
    Max pressure: 0.005Mpa
    Hail resistance: Ø25mm
    Anti Freezing: -20°C
    Wind resistance: 20m/s
    Instruction manual: Available



    FAQ:

    Q1: Can I get any discount?

    A1:

    The Price is negotiable, we can offer you discount according to your order quantity. If you purchase it with container loading quantity, we can offer you some discount. For LCL goods, it needs extra wooden case fee.



    Q2: How long will it take for my goods to receive?

    A2:

    Normally it need about 30 days to ship to European Countries and America by sea.



    Q3: How much are the shipping costs?

    A3:

    Shipping cost is charged by the measurement and shipping port.



    Q4: Do you offer samples for free?

    A4:

    Unfortunately we do not supply free samples.



    Q5:How do I place my order?

    A5:

    You can send us an inquiry letter first, we will contact you in 24 hours and guide you how to order.



    Q6: How to contact us?

    A6:

    Please send your Inquiry to our email or call us by tel/cell no.
