Home ProductsHeat Pipe Solar Collector

Silver Coating Heat Pipe Solar Collector 15 Tube Rockwool Polyurethane Insulation

Silver Coating Heat Pipe Solar Collector 15 Tube Rockwool Polyurethane Insulation

    • Silver Coating Heat Pipe Solar Collector 15 Tube Rockwool Polyurethane Insulation
    • Silver Coating Heat Pipe Solar Collector 15 Tube Rockwool Polyurethane Insulation
    • Silver Coating Heat Pipe Solar Collector 15 Tube Rockwool Polyurethane Insulation
  • Silver Coating Heat Pipe Solar Collector 15 Tube Rockwool Polyurethane Insulation

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 15tubes

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Tubes: 15 Tubes Insulation: Rock Wool
    Frame: Aluminum Alloy Installation: Pitched Roof
    Heat Pipe: 24mm Condenser Copper Manifold Color: Silver Coating
    Structure: Heat Pipe Application: Swimming Pool

    Silver Coating Heat Pipe Solar Collector 15 Tube Rockwool Polyurethane Insulation



    Working Principle:



    high pressure heat pipe solar collector is one of the most popular solar collector with pretty high efficiency.

    The selective coating of vacuum tubes converts solar irradiation into heat energy and transfers to copper heat pipes by aluminum wrapping.

    The heat transfer liquid in heat pipe then vaporize and rapidly rise to the top condenser.

    In active system, a pump circulates water or heat transfer fluid through the manifold header pipe, taking away the heat to store in tank water.

    The cooled vapor in heat pipe then liquefies and returns to pipe bottom, waiting for another heat circulation in few seconds.



    Heat Pipe Solar Collector

    HEAT PIPE

    VACUUM TUBE

    Tube Size Ø58mm X 1800mm Absorption rate≥93%
    Tube Structure All glass double deck co-axial structure
    Coating Material Three-Target [ALN/ALN-SS/CU]
    Glass Material Borosilicate 3.3 glass; Thickness is 1.6±0.15mm
    Copper Heat Pipe

    1700mm length Dia:0.8mm, Wall thickness 0.7/0.8mm

    Condenser Dia:14mm,Can bear -50℃

    Aluminum Fin Compact type, thickness 0.25mm
    MANIFOLD

    Outside: Aluminum Alloy, Thickness 2.0mm

    Main Flowing Copper Pipe: Dia.35/38mm; Wall thickness 1.0mm

    Insulating Layer: Rock wool thickness 30mm

    BRACKET Material Aluminum Alloy
    Thickness 1.8mm
    Angle 12°~60°
    ANTI-PRESSURE 1.5Mpa;Anti-cold -50C
    PACKAGE Corrugated Cartons + EPS Foam
    LOGO Free
    PORT OF LOADING Shanghai or Ningbo CHINA
    LEADING TIME 15 DAYS
    MOQ 1 Set
    PAYMENT TERMS T/T/ PAYPAL/ Western Union/Trade Assurance
    CERTIFICATIONS SOLAR KEYMARK / CE /SRCC / ISO9001 / ISO14001 / CCC
    WARRANTY 10 Years



    Loading Quantity



    Model Tube Tube Q.T.Y Loading Q.T.Y/40HQ
    15 58*1800mm 15pcs 315sets
    18 58*1800mm 18pcs 265sets
    20 58*1800mm 20pcs 248sets
    22 58*1800mm 22pcs 225sets
    25 58*1800mm 25pcs 200sets
    30 58*1800mm 30pcs 168sets



    Our service



    We have both vacuum tubes factory and water tank factory for more than 8 years.

    We provide 6 years Warranty for the whole system.

    Keep the delivery time exact.

    Your inquiry will be replied within 12 hours.

    We offer you professional service with fluent English.

    Keep the bulk production as the samples in high quality.

    Freight forwarder: faster, safer and convenient.

    Quality : we have QC in each process.



    Packaging & Delivery



    Packaging Details: Export carton for full container.

    Delivery Detail: 7 days after receiving the deposit.

    Packing details:



    Exporting Carton with big foaming protection
    Packing size of Heat Pipe Solar Collector
    Heat pipe vacuum tube:
    10pcs/ctn:197*34*17cm
    12pcs/ctn:197*28*24cm
    15pcs/ctn:197*34*24cm


    Manifold and bracket:
    15:/18/20:200*1618cm
    22:200*16*20cm
    25:205*16*20
    30:241*16*20cm



    Warranty



    6 years international responsibility for heat pipe solar collector and 15 years for vacuum tubes due to original quality problems.
