Black Frame Solar Collector 10-30tubes Heat Pipe Solar Thermal Panel

Black Frame Solar Collector 10-30tubes Heat Pipe Solar Thermal Panel
Black Frame Solar Collector 10-30tubes Heat Pipe Solar Thermal Panel Black Frame Solar Collector 10-30tubes Heat Pipe Solar Thermal Panel Black Frame Solar Collector 10-30tubes Heat Pipe Solar Thermal Panel

Large Image :  Black Frame Solar Collector 10-30tubes Heat Pipe Solar Thermal Panel

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 10-30tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

Black Frame Solar Collector 10-30tubes Heat Pipe Solar Thermal Panel

Description
Tubes: 10-30 Tubes Insulation: Rock Wool
Frame: Aluminum Alloy Installation: Flat Roof
Heat Pipe: 14/24mm Condenser Copper Manifold Color: Black/Silver
Principle: Pressurized Application: Apartment
High Light:

Black Frame Solar Collector

,

Flat Roof Heat Pipe Solar Collector

,

Alu Alloy Heat Pipe Solar Collector

Black Frame Solar Collector 10-30tubes Heat Pipe Solar Thermal Panel



Specifications



Heat pipe solar collector, made for split solar system
SRCC,EN12975,SolarKeymark,CCC,ISO9001
10 years warranty
OEM



Specification of heat pipe solar heat collectors



Manifold (interior): red copper

Manifold (exterior): aluminum alloy

Glass tube dimensions: 58mm x 1.8m
Daily efficiency: ≥55% (≥42% in winter )

Hail resistance: 25mm

max pressure: 12 bar

Coating of vacuum tube: ALN/AIN-SS/CU

Heat Pipe: anti-freezing > -35 °C

Inlet/outlet: 22mm(3/4″)

manifold casing: silver (AL original), Black



Model name 12-58/1800 15-58/1800 20-58/1800
number of tubes 12 15 20
Gross size(mm) 1010*1980 (W*L) 1235*1980 (W*L) 1610*1980 (W*L)
aperture area M2 1.108 1.397 1.876
Absorber area M2 0.964 1.199 1.603
flat roof installation size 1420*1010*1420mm (L*W*H) 1420*1235*1420mm (L*W*H) 1420*1610*1420mm (L*W*H)
weight empty (KG) 40.7 56 64.4
fluid volume( L) 0.8 1 1.37
Heat transfer medium pure water/glycol pure water/glycol pure water/glycol
working pressure 6 bar 6 bar 6 bar
Max testing pressure 12 bar 12 bar 12 bar
Max working temperature 280°C 280°C 280°C
efficiency n° 0.788 0.79 0.795
inlet/outlet connection 22mm 22mm 22mm
manifold packing mm 1*2000*200*160 1*2000*200*160 1*2000*200*160
tubes packing mm 1*1940*280*270 1*1940*350*270 2*1940*350*180
certificate EN12975-1,2 SOLAR KEYMARK EN12975-1,2 SOLAR KEYMARK EN12975-1,2 SOLAR KEYMARK

Material
vacuum tube high borosilicate glass
size 58*1800mm
coating SS-CU-AIN/ALN
heat pipe material TU1 copper
heat pipe length 1790mm
heat pipe diameter condenser dia14mm, body dia 8mm
manifold header pipe TP2 copper dia 35mm
manifold casing anodized aluminum alloy
insulation rock wool with polyurethane foam
bracket galvanized steel
tube holder UV stabilized nylon
seals silicon seal
contact sheets aluminum fin



Service



The Solar Pool Heating System can be combined with a solar home heating system or solar water heating system to provide the maximum benefits and return on your investments.

Call us and we will help you build a solar heating solution for both your pool and home.

With professional experience the best solar pool heating system is put forward for your particular circumstances.



These are some Factors to be considered in design of a solar pool heating system:

Location of your home.

Pool size( L×W×H ).

Duration of the swimming season.

Initial temperature for the water.



Why choose us?



we have our clients set to list of reasons why to choose us over other solar water heater,here are our benefits

Engaged in the solar energy application technology for more than 18 years

We has received many honors and passed multiple verification.

The number of service outlets across the country, so you have no worry.

We research and produce all kinds of products , widely used in hospitals, schools, hotels, etc.



Tips



· Considering the economics of a solar water heating system

· Evaluate your site's solar resource

· Determine the correct system size

· Determine the system's energy efficiency.
