Product Details:
|
Capacity: | 500L/1500L | Structure: | Split |
---|---|---|---|
Flat Plate: | Blue Titanium | Principle: | Pressurized |
Collector: | Flat Plate | Inner Tank: | Stainless Steel 304/316 |
Bracket: | Stainless Steel 201 0/20/30/45 Degrees | Material: | Copper Aluminum |
High Light: | Titanium Split Solar Hot Water System,400L Split Solar Hot Water System,304SS Tank Split Solar Water Heater |
400L Split Pressure Solar Water Heating 304 Stainless Steel Solar Water Heater Tank
Capacity:
100L-1500L.
Flat Plate Solar Water Heater Description:
Flat plate Solar Water Heater is one of common Solar Water Heater for solar water-heating system in homes and room heating.
Flat plate Solar Water Heater provide quality hot water with its new solar energy efficient flat plate design.
The flat plate solar collector includes a selective coating to maximize the solar heat absorption,
aluminum framing and interior fiberglass insulation for increased efficiency.
Advantage:
1. Highly efficient absorber of high performance with daily average efficiency over 76%;
2. Blue film absorber with automatic production line,can supply you stable high quality products;
3. Withstand pressure of 6 Bar, can be connected directly with city water or your big water tank;
4.Simple structure, easy to assembly and install in short time, no breakage;
5.Best insulation with polyurethane foam;
6.Can be used all year round in the cold climate;
7.Can be used together with auxiliary electric boost;
8.Long service life, can be used over 15 years;
Flat Plate Solar Water Heater Features:
1.Using patent advanced coating technology with high efficiency performance.
2. High strength aluminum-alloy structure with surface varnish baking
3. High visual shape ,easy installation ,maintenance free
4. Pressurized designing, operate with pressure up to 1 Mpa
5. Can be combined with existing energy source
Flat Plate Solar Collector Technical Data :
Model |
PT-F-AO |
PT-F-BC |
PT-F-BT |
|||
Data |
||||||
Dimension LxWxH (mm) |
2000*1000*80 / 2000*1250*80 / 2000*1500*80 |
|||||
Gross Area (m2 ) |
2.00 |
|||||
Absorber Area (m2 ) |
1.9 |
|||||
Number of covers |
1 |
|||||
Cover Material |
Low iron tempered textured glass |
|||||
Cover Thickness(mm) |
3.2 |
|||||
Cover Transmission |
>91.7% |
|||||
Weight (KGS) |
29 |
|||||
Absorber |
||||||
Absorber material |
Aluminium Plate |
|||||
Absorber coating |
Anode Oxidation |
Black Chrome |
Blue Titanium |
|||
Welding |
Laser welding/Ultrasonic welding |
|||||
Construction Type |
Grid type |
Grid type |
Grid type |
|||
Header Material |
Copper TP2 |
Copper TP2 |
Copper TP2 |
|||
Header pipe |
Red copper/ Φ22*0.6*2 PCS |
|||||
Riser Material |
Copper TP2/CA1220 |
|||||
Riser pipe |
Red copper/ Φ8*0.5*7 PCS/Φ10*0.5*7 PCS |
|||||
Work Pressure |
0.6Mpa |
|||||
Test pressure |
1.2Mpa |
|||||
Thermal Insulation |
||||||
Insulation Material |
Fiberglass |
|||||
Insulation Thickness |
40mm |
|||||
Casing |
||||||
Frame |
Aluminium alloy |
|||||
Frame Colour |
Silver/Black |
|||||
Back Plate |
Galvanized steel |
|||||
Sealing Gasket |
EPDM |
Packing:
LCL( Less than Container Load ):Wooden case
FCL( Full Container Load ):Export carton
Delivery:
Usually, it is 10 Working days after receiving deposit or original L/C.
