1000L 3000L Building Solar Heating Stainless Steel Split Pressurized Solar Water Heater

1000L 3000L Building Solar Heating Stainless Steel Split Pressurized Solar Water Heater

    • 1000L 3000L Building Solar Heating Stainless Steel Split Pressurized Solar Water Heater
    • 1000L 3000L Building Solar Heating Stainless Steel Split Pressurized Solar Water Heater
    • 1000L 3000L Building Solar Heating Stainless Steel Split Pressurized Solar Water Heater
  • 1000L 3000L Building Solar Heating Stainless Steel Split Pressurized Solar Water Heater

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 2000L/1500L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Capacity: 2000L/1500L Structure: Split System
    Flat Plate: Black Chrome Principle: Pressurized
    Collector: Flat Plate Inner Tank: Stainless Steel 304/316
    Bracket: Stainless Steel 201 0/20/30/45 Degrees Material: Copper Aluminum
    High Light:

    residential solar water heater

    ,

    split pressurized solar water heater

    1000L 3000L Building Solar Heating Stainless Steel Split Pressurized Solar Water Heater



    Capacity:

    1000L/1500L/2000L/3000L.



    Flat Plate Solar Water Heater Description:

    Flat plate Solar Water Heater is one of common Solar Water Heater for solar water-heating system in homes and room heating.

    Flat plate Solar Water Heater provide quality hot water with its new solar energy efficient flat plate design.

    The flat plate solar collector includes a selective coating to maximize the solar heat absorption,

    aluminum framing and interior fiberglass insulation for increased efficiency.



    Advantage:

    1. Highly efficient absorber of high performance with daily average efficiency over 76%;
    2. Blue film absorber with automatic production line,can supply you stable high quality products;
    3. Withstand pressure of 6 Bar, can be connected directly with city water or your big water tank;
    4.Simple structure, easy to assembly and install in short time, no breakage;
    5.Best insulation with polyurethane foam;
    6.Can be used all year round in the cold climate;
    7.Can be used together with auxiliary electric boost;
    8.Long service life, can be used over 15 years;



    Flat Plate Solar Water Heater Features:

    1.Using patent advanced coating technology with high efficiency performance.

    2. High strength aluminum-alloy structure with surface varnish baking

    3. High visual shape ,easy installation ,maintenance free

    4. Pressurized designing, operate with pressure up to 1 Mpa

    5. Can be combined with existing energy source



    Flat Plate Solar Collector Technical Data :



    Model

    PT-F-AO

    PT-F-BC

    PT-F-BT

    Data

    Dimension LxWxH (mm)

    2000*1000*80 / 2000*1250*80 / 2000*1500*80

    Gross Area (m2 )

    2.00

    Absorber Area (m2 )

    1.9

    Number of covers

    1

    Cover Material

    Low iron tempered textured glass

    Cover Thickness(mm)

    3.2

    Cover Transmission

    >91.7%

    Weight (KGS)

    29

    Absorber

    Absorber material

    Aluminium Plate

    Absorber coating

    Anode Oxidation

    Black Chrome

    Blue Titanium

    Welding

    Laser welding/Ultrasonic welding

    Construction Type

    Grid type

    Grid type

    Grid type

    Header Material

    Copper TP2

    Copper TP2

    Copper TP2

    Header pipe

    Red copper/ Φ22*0.6*2 PCS

    Riser Material

    Copper TP2/CA1220

    Riser pipe

    Red copper/ Φ8*0.5*7 PCS/Φ10*0.5*7 PCS

    Work Pressure

    0.6Mpa

    Test pressure

    1.2Mpa

    Thermal Insulation

    Insulation Material

    Fiberglass

    Insulation Thickness

    40mm

    Casing

    Frame

    Aluminium alloy

    Frame Colour

    Silver/Black

    Back Plate

    Galvanized steel

    Sealing Gasket

    EPDM



    Packing:

    LCL( Less than Container Load ):Wooden case

    FCL( Full Container Load ):Export carton



    Delivery:

    Usually, it is 10 Working days after receiving deposit or original L/C.

    1000L 3000L Building Solar Heating Stainless Steel Split Pressurized Solar Water Heater 01000L 3000L Building Solar Heating Stainless Steel Split Pressurized Solar Water Heater 1
