Product Details:
|
| Pipe Material: | Flexible | MOQ: | 100M |
|---|---|---|---|
| OD & ID: | DN12 Twin | Insulation Material: | EPDM Pre Insulated |
| Jacketing Protection: | Seamless ,uv-resistance,PE-HD | Sensor Cable: | Silicon 2-core |
| Package: | Cartons | Application: | Solar Water Heater Accessories |
| High Light: | hot water heater accessories,solar hot water spare parts |
||
DN12 Twin EPDM Pre Insulated Flexible Solar Hose Pipe for Solar Water Heater Accessories
Specifications
Flexible solar hose
Seamless UV-Resistance, passed 500hours UV test
EPDM insulation pipe
Anneal CSST
DN12 Twin EPDM pre Insulated Flexible Solar Hose Pipe for Solar Water Heater
| Item Name | DN12 Twin EPDM pre Insulated Flexible Solar Hose Pipe for Solar Water Heater |
| Part No. | PT16025.13 |
| Size | DN12 |
| OD & ID | 16mm*12mm |
| Material | stainless steel |
| MOQ | 100 meters |
| Original | China |
Introduction
pre insulated flexible solar hose only require 1 step to finish the Solar Water Heater Pipe Installation.
Our pre-insualted flexible stainless steel Solar Hose with high temperature EPDM insulation pipe.
Strong Jacket protection and 2-core temperature sensor cable pre assemble.
It is an ideal choice for your solar thermal system.
It realizes the fast pipe connection among solar collectors, the pump station and the water tank. Non-welding required.
The system is light weight and space saving, which is easy to handle, even in confined spaces. Flow and return pipes are marked clearly and can be easily distinguished.
Smart Design- Break Point does good to installer separate twin pipes into 2 pipes without any destroy of the jacket protection, meeting the installation demand very well.
Application
Piping systems for solar hot water, heating, heat pumps and air conditioning technology indoor, outdoor or underground piping system.
Structure
Twin flexible solar hose: It consisting of high temperature resistance EPDM insulation, 2 x flexible corrugated stainless steel tubes (feed and return), UV-resistant, Silicone-sensor line, seamless jacket protection.
Single flexible solar hose: It Consisting of high temperature resistance EPDM insulation, 1 x flexible corrugated stainless steel tube, UV-resistant, seamless jacket protection.
Single flexible solar hose with Temperature Sensor Cable It Consisting of high temperature resistance EPDM insulation, 1 x flexible corrugated stainless steel tube (feed and return), UV-resistant, Silicone-sensor line, seamless jacket protection.
Twin Flexible Solar Hose Features
Specifically designed for solar thermal panels.
Each coil includes both the feed and return pipes.
Easy to distinguish the feed pipe and return pipe.
Our Sensor cable is on one side of the twin pipe, which is easy to distinguish the feed pipe and return pipe line
Flexible high-grade corrugated stainless steel tube 316L(or 304).
Maximum pressure up to 17.5 bar, Rated burst pressure 200 bar,food grade, passed 500hours UV test, annealing heat treatment.
100% Genuine EPDM insulation pipe. Light, flexible, closed cell, synthetic caoutchouc.
free of PVC and non- CFC.Very good ozone resistance, UV-resistant.
Work Temperature range from -200°C to 150°C,Max to 175°C.
Seamless UV resistant Jacketing coated on the insulation pipe is with a super high density water proof polyolefin copolymer foil.
have excellent performance of UV-resistance , of strong tenacity performance, water proof , Machinery destroy-Protective and bird peck-Protective, passed 500hours UV test
Coil length is available in 10, 15,20,30,60 meters.
Other length is available upon customer's request
Save money. Easy connection, no soldering required, Saves installation time, reduction costs.
Each Twin pipe can be separated from the joint point into 2 complete single pipes according to the installation requirements.
Save time, Save space ,Save labor cost, Realize the fast , easy and reliable solar pipes installation
