High Absorption Flat Plate Solar Collector Anodised Aluminium Alloy Frame

High Absorption Flat Plate Solar Collector Anodised Aluminium Alloy Frame
High Absorption Flat Plate Solar Collector Anodised Aluminium Alloy Frame High Absorption Flat Plate Solar Collector Anodised Aluminium Alloy Frame

Large Image :  High Absorption Flat Plate Solar Collector Anodised Aluminium Alloy Frame

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 2 sqm
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

High Absorption Flat Plate Solar Collector Anodised Aluminium Alloy Frame

Description
Header Material: Copper TP2 Header Pipe: Red Copper
Absorber Material: Aluminum Full Plate Cover Material: Wove Toughened Glass
Frame: Anodised Aluminium Alloy Dimension LxWxH (mm): 2000*1000*80
Collector: Flat Plate Insulation Material: Fiberglass
High Light:

solar water heater collector

,

flat panel solar collector

High Absorption Blue Titanium Flat Plate Solar Collector Anodised Aluminium Alloy Wove Toughened Glass



Feature



1. high efficiency &attractive appearance.

2. customized service.

3. easy installation and flow maintenance.

4. low cost & high socio-economic benefits.

5. 15 years' life span with 5 years warranty.

6. well wind , snow and hailstone resistance.



Working Principle



Solar radiation passes through transparent cover plate and reaches heat absorbed layer of plate . The water inside the copper pipe becomes hot and rise in the top of the water tank .

So the hole system is always circulating continuously heating .



Detail Specification flat plate collector



dimension: 2000*1000*80mm

the work temperature:- 35C-200C

the work pressure: 0.8Mpa

it can generate 100L hot water (50Celsius) per day

the aluminum shell

the boronsillicon glass cover

all copper material conduct medium in the collector

We can provide the clients the whole set include water tank solar collector and work station,the clients also can purchase the collector only,them can be optional



Comply with SOLAR KEYMARK/CE
  EN12975
Fins Aluminum absorber type
Tube for pump circulation 8 * δ0.5 *1886, 8pcs copper
Manifold tube for grids 22 * δ0.8*1060 ,2pcs copper
Minimum efficiency 80%-90%
Absorption factor absorption~95%
Emission factor emission ~18%
Insulation Back: 30 mm fiber glass cotton ,30kg/sq.m
  Side: 15mm fiber glass cotton, 60kg/sq.m
Glazing

4mm tempered glass

Fixed on casing by silicon or EPDM

Area available 5m2(2*2.5m)--roof mounted.
Backing Sheet 0.3mm galvanized plate
Net Weight(kg) 32.5
Gross Weight(kg) 37
Working Pressure 0.6Mpa
Testing Pressure 1.2Mpa for 5 minutes
Net dimension L*W*T(mm) 2000*1000*80
Package Dimension(mm) 2010*1010*95
Package Cartoon
Cartoon size 0.2CBM



Packaging & Delivery



Packaging Details: STANDARD EXPORT CARTONS,WOODEN BOX FOR SAMPLES.

Delivery Detail: 15DAYS FOR FULL CONTAINERS,10 DAYS FOR SAMPLES.



Terms:



1. OEM or Customized design available.
2. Payment terms: 30% in advance and 70% against copy of B/L or L/C, For sample T/T 100% in advance.
3. Delivery terms: 15 working days after receiving deposit or original L/C.
4. Warranty: 5 years.

5. Minimum quantity: 3
6. Package:

Standard export package with Logo or the package you want on the basis of OEM.

For LCL, extra wooden boxes will be added.



Warranty:

10 years international responsibility for Flat Plate Panel Solar Collector due to original quality problems.



FAQ



Payment terms: T/T, L/C, Paypal, Western union all support

Delivery time: Sample order 3 working days, Container order 10 working days.

Minimum order quantity: 1 PC

Guarantee period:5 years

OEM service: Support (Print logo on carton for free)
