Home ProductsThermal Solar Collector

Big Capacity Vacuum Tube Thermal Solar Collector High Density 25 / 50 Tubes

Big Capacity Vacuum Tube Thermal Solar Collector High Density 25 / 50 Tubes

    • Big Capacity Vacuum Tube Thermal Solar Collector High Density 25 / 50 Tubes
    • Big Capacity Vacuum Tube Thermal Solar Collector High Density 25 / 50 Tubes
  • Big Capacity Vacuum Tube Thermal Solar Collector High Density 25 / 50 Tubes

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 25/50Tubes

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T, D/P
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Capacity: 25/50 Tubes Application: Indoor Swimming Pool
    Warranty: 6 Years Insulation: High Pressure Polyurethane Foam
    Collector: Vacuum Tube Circulation Type: Open Loop
    Outer Tank: Color Steel Inner Tank: Stainless Steel 304

    Project Solution Stainless Steel Vacuum Tube Thermal Solar Collector for Indoor Swimming Pool



    Solar Collector for Project

    Can be a cost-effective way to generate hot water for your home.

    They can be used in any climate, and the fuel they use (sunshine) is for free.



    We are professional split and pressurized solar water heater, pressurized solar collector, non-pressurized solar collector for project, domestic solar water heater, solar thermal hot water Manufacturer.





    Direct Flow Vacuum Tube Solar Collector For Project



    Features

    1. Use high quality evacuated tubes maximize the daily output.

    2. Quality 304 stainless steel special for sea side and high air pollution area.

    3. standard food grade 304 2 B stainless steel inner tank with perfect tank design ensure the reliable quality.

    4. High density import Polyurethane insulation with a perfect performance of reduce the heat lose of the water tank.

    5. Big capacity



    Technical Data



    Max. Work pressure: 1.5 bar

    Absorption rate > 93%

    Max. wind resistance: 17m/s

    Max. Hall resistance: 25mm in diameter

    Work temperature: from -10 C to 200 C



    Vacuum tube solar collector applications
    1. Hotels, resorts, hospitals and hostels
    2. Process industry, boiler feed, laundry and canteens
    3. Agricultural sector, hatcheries and dairies
    4. Process industry, Boiler feed, Laundry and canteens
    5. Agricultural sector, hatcheries, and dairies
    6. Swimming pool heating
    7. In-process heating
    8. Health clubs (Steam / Sauna)



    The Solar Collector Manifold Information



    Description Direct flow Vacuum Tube Solar Collector for Project with SRCC,SPF approved
    Material of inner tank Food grade SUS 304 2B stainless steel
    Material of out tank SUS 304 BA or 2B stainless steel
    Insulation of tank 55mm high-density import polyurethane foamed
    Frame SUS 304 stainless steel
    Size of Inlet and Outlet 1/2 male or 3/4 male
    Vent and overfolw 1/2 male
    Electrical heater hole 47mm or 3/4 female
    Fittings stainless steel screw
    Vacuum tubes details
    Vacuum tubes 3.3 Borosilicate glass double wall with AL/N/Al selective absorb layer, thickness of glass:1.6mm
    max pressure of tube 0.6 bar
    Guarantee of vacuum tubes 10 years



    The Solar collector information

    Model

    Tubes

    Qty.

    Supply hot water Absorbing Area

    Weight

    (KGS)

    Installing Dimension

    (L× W× H)

    Qty.

    20FT/40FT/40HQ

    SC-58-50 50 415L 3.81m^2 121 2100*190*190mm 34 /67/82















    Warranty



    5 years international responsibility for vacuum tube solar collector and 15 years for glass vacuum tubes due to original quality problems.



    REMARK



    We are the leading solar collector manufacturer in CHINA,

    With high quality and competitive price under standards of: SOLAR KEYMARK/EN-12975, SRCC, and CE &ISO.



    FAQ



    Model selection: Usually we suggest Φ58*1800MM tube solar collector which is more cost effective.



    Technical support: offers design and installation instruction for customers with our 10 years installation experience.



    OEM: Your LOGO information can be made on our Manifold Vacuum Tube Solar Collector and carton boxes.



    ODM: Design manufacturing is available for manifold size and shape, tube length, frame structure, etc.

    Big Capacity Vacuum Tube Thermal Solar Collector High Density 25 / 50 Tubes



    PDF Catalogue of Non Pressure Solar Collector.

    PT-NC Non Pressure Solar Collector.pdf
