Aluminum Alloy Heat Pipe Solar Collector For Low Temperature Area 15 Tubes

Aluminum Alloy Heat Pipe Solar Collector For Low Temperature Area 15 Tubes
Aluminum Alloy Heat Pipe Solar Collector For Low Temperature Area 15 Tubes Aluminum Alloy Heat Pipe Solar Collector For Low Temperature Area 15 Tubes

Large Image :  Aluminum Alloy Heat Pipe Solar Collector For Low Temperature Area 15 Tubes

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 15tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

Aluminum Alloy Heat Pipe Solar Collector For Low Temperature Area 15 Tubes

Description
Heating Collector: 15 Insulation Thickness: 45mm
Bracket: Aluminum Alloy Installation: Pitched Roof
Heat Pipe: 14mm Condenser Copper Manifold Color: Silver
Area: Low Temperature Area Application: Apartment
High Light:

heat pipe vacuum tube solar collector

,

pressurized solar collector

Aluminum Alloy​ Heat Pipe Solar Collector Room Heating System Used in Low Temperature Area



How the heat pipe collector works:



Step 1: Sunlight is absorbed inside the evacuated tube causing it to heat up.

Step 2: The heat pipe inside the tube carries this thermal energy up to the manifold box.

Step 3: Fluid circulates from the storage tank up through to the header pipe and extracts the energy from the hot heat pipe tips.

Step 4: The newly heated fluid circulates back to the storage tank where it can be used and the cycle begins again.



Specifications:



Heat pipe solar collector
Recycled glass wool insulation
Superior anti-freeze
Anti-corrosion copper
Rapid heat transfer



Features:



· Copper heat pipes for rapid heat transfer

· 3/4" copper head connections

· Recycled glass wool manifold insulation

· Corrosion resistant silver brazed copper header

· Recycled glass wool manifold insulation

· Low heat loss

· Efficient performance at high differential temperatures

· Easy plug-in installation

· Maintenance Free

· Suitable for mains pressure water



MARKET



Popular country: Europe, USA,Canada, Russia, UAS, Australia, New Zealand, Mexico, Korea, Brazil, Peru, and etc.



APPLICATIONS



1. Hotels. Resorts. Hospitals and hostels

2. Process industry.

3. Agricultural sector. Hatcheries and dairies

4. Boiler feed. Laundry and canteens

5. Swimming pool heating

6. In-process heating

7. Health clubs



PACKING & CARTON DETAILS



Exporting standard carton or wooden boxes for sample.

Inner poly bag with outer export carton packing.



Type PT-10 PT-15 PT-20 PT-25 PT-30 PT-15B PT-30B
Number of tubes 10 15 20 25 30 15 30
Gross area (m²) 1.63 2.40 3.17 3.93 4.70 1.33 2.42
Aperture area (m²) 0.94 1.41 1.88 2.35 2.82 0.63 1.30
Absorber area (m²) 0.805 1.24 1.65 2.06 2.48 0.54 1.08
Peak power (W / Collector) 659 900 1199 1499 1799 450 900
Allowable operating pressure (bar) 6 6 6 6 6 6 6
Test pressure (bar) 10 10 10 10 10 10 10
Max. stagnation temperature 232°C 200°C 200°C 200°C 200°C 200°C 200°C
Max. operating temperature 95°C 95°C 95°C 95°C 95°C 95°C 95°C
Flow rate (l / m2h) 50-150 50-150 50-150 50-150 50-150 50-150 50-150
Absorber material CU/AI/SS/N2 Borosilicate glass
Coating ALN/SS-ALN/CU
Absorption coefficient ≥ 94% ≥ 94% ≥ 94% ≥ 94% ≥ 94% ≥ 94% ≥ 94%
Emission coefficient ≤ 7% ≤ 7% ≤ 7% ≤ 7% ≤ 7% ≤ 7% ≤ 7%
Weight (kg) 36.4 55 77 96 116 32 65
Liquid content 0.62L 0.93L 1.24L 1.55L 1.82L 0.93L 1.82L
Mounting angle 15 - 75° 15 - 75° 15 - 75° 15 - 75° 15 - 75° 15 - 75° 15 - 75°
Frame 2mm Aluminum Alloy
Heat pipe 8mm red copper
Long-term stable vacuum (Pa) <5*10-3 <5*10-3 <5*10-3 <5*10-3 <5*10-3 <5*10-3 <5*10-3
Glass tube diameter 58mm 58mm 58mm 58mm 58mm 58mm 58mm
Vacuum tube wall thickness 1.6mm 1.6mm 1.6mm 1.6mm 1.6mm 1.6mm 1.6mm
Insulation Compressed Rockwool
Collector width 800mm 1175mm 1550mm 1925mm 2300mm 1175mm 2300mm
Collector length 2043mm 1200mm
Manifold 38mm red copper
Tube length 1800mm 850mm
Pressure drop <5mbar(80L/h), 12mbar (150L/h)
