Eco Friendly Shower Solar Water Collector , Heat Pipe Collector OEM Available

Eco Friendly Shower Solar Water Collector , Heat Pipe Collector OEM Available
Eco Friendly Shower Solar Water Collector , Heat Pipe Collector OEM Available Eco Friendly Shower Solar Water Collector , Heat Pipe Collector OEM Available Eco Friendly Shower Solar Water Collector , Heat Pipe Collector OEM Available Eco Friendly Shower Solar Water Collector , Heat Pipe Collector OEM Available

Large Image :  Eco Friendly Shower Solar Water Collector , Heat Pipe Collector OEM Available

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 15tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

Eco Friendly Shower Solar Water Collector , Heat Pipe Collector OEM Available

Description
Collector Tubes: 15 Tubes Insulation: High Pressure Polyurethane
Bracket: Aluminum Alloy Assembly: Flat Roof
Heat Pipe: 24mm Condenser Copper Manifold Color: Silver
Angle Of Bracket: 0 Degree Application: Shower
High Light:

heat pipe vacuum tube solar collector

,

pressurized solar collector

Aluminum Alloy Manifold Pressure Passive Heat Pipe Solar Collector Antifreezing for Shower



Specifications:



1. CE,Solar keymark,CCC,ISO,SGS
2. OEM service
3. factory more than 11 years
4. 5 years warranty



Details:



Brand name PT
Place of origin Zhejiang,china
Type Vacuum tube
Pressure 0.6MPa
Tube heat pipe
Bracket aluminum alloy/galvanized steel
Hail resistance diameter 25mm
Installation freestanding
Certificate CE,SK(EN12975)
  CCC, ISO9001 SGS
Number of tubes 12/15/20/25/30/36
Use water heater/air conditioning system



Feature:



1. Solar radiation is absorbed by the tubes and converted into heat,heat pipes conduct th heat from the copper tube up to the header pipe.

2. Anti-freeze liquid is circulated through the header ,via intermittant pump cycling.

3. There is no water in the tubes ,so the tube will not break in the winter.

4. It can be still operate in the event of occasional tube breakages

5. Water tank do not need be installed above the collector

6. It can be installed both on pitched roof and flat roof



Parameter List



Model-tubes Number of tubes Absorb area
PT12-58/1800 12 tubes(heat pipe) 1.56m²
PT15-58/1800 15 tubes(heat pipe) 1.95m²
PT20-58/1800 20 tubes(heat pipe) 2.60m²
PT25-58/1800 25 tubes(heat pipe) 3.25m²
PT30-58/1800 30 tubes(heat pipe) 3.90m²
PT36-58/1800 36tubes(heat pipe) 4.68m²


1. Heat is transferred in one-way. Little capacity. The heat pipe starts to work fast at low degree.
2. Thermal conductivity working fluid and metal material commonly used has a good compatibility.
3. The vacuum tube will not burst even the temperature of tube gets 300º C at least, for adopting inorganic element.

The vacuum tube will not frozen even the temperature of tube gets minus 400º C for having good low-temperature-resistance.
4. Heat pipe owns super thermal conductivity with almost no resistance.
Thermal conductivity is more than 7000 times of silver. The power can be 26000kw/m2.



Size & Weight & Load



    PT-12 PT-15 PT-18 PT-20 PT-25 PT-30
Size (m3) Manifold & stand 0.061 0.061 0.061 0.061 0.061 0.072
Tube 0.14 0.17 0.24 0.25 0.293 0.34
Total volume 0.201 0.231 0.301 0.311 0.354 0.412
Weight(kg) Manifold & stand 11 14 15.5 17 24 31
Tube 33 41 48 54 68 82
Total weight 44 55 63.5 71 92 113
Loading(set) 20GP 148 128 96 94 79 68
40GP 297 258 196 191 163 142
40HC 347 302 229 223 192 165



Warranty & Service



Warranty: 6 years

If some problem happens which is relative to our quality, we are absolutely responsible for it.

Contact with us at anytime, we will solve it in time.
