Product Details:
|
| Tubes: | 15 Tubes | Insulation: | Glass Wool |
|---|---|---|---|
| Mounting: | Aluminum Alloy | Installation: | Flat Roof |
| Heat Pipe: | 24mm Copper Condenser | Manifold Color: | Silver |
| Angle Of Bracket: | 45 Degree | Application: | Room Heating |
| High Light: | pressurized solar collector,solar hot water collector |
||
Silver Color Glass Wool Heat Pipe Solar Collector 24mm Copper Condenser Flat Roof
How it works:
1) The operation of the solar collector is very simple.
2) Solar absorption: solar radiation is absorbed by the solar tubes
and converted into heat.
3) Solar heat transfer: heat pipes conduct the heat from within the
solar tube up to the header pipe
4) Solar energy storage: water is circulated through the header,
via intermittent pump cycling. Each time the water circulates through
the header, the temperatures is raised by 5-10C. Throughout the day,
the water in the tank is gradually heated.
Structure
1) Manifold casing material: 304 stainless steel or powder coated aluminum.
2) Frame material: 304 stainless steel.
3) Heat-pipe material: C12200 COPPER, OD:58MM, L:1800MM.
4) Insulation: Rock wool; Rubber seals and rings: UV stabilized high temperature silicone rubber.
5) Maximum operating pressure: 6bar-85psi.
Specifications
| Model | Absorbing Area(m2) | Heat pipe vacuum tube | Water Temperature (Centigrade) |
Loading Qty(sets) 20"/40" |
||
| Ø(mm) | L(mm) | NO.(PCS) | ||||
| PT-47/1500-12 | 1.2 | 47 | 1500 | 70 | 60 | 141/295 |
| PT-47/1500-15 | 1.5 | 47 | 1500 | 70 | 60 | 120/270 |
| PT-47/1500-18 | 1.8 | 47 | 1500 | 120 | 60 | 95/198 |
| PT-47/1500-20 | 2.0 | 47 | 1500 | 120 | 60 | 85/178 |
| PT-47/1500-24 | 2.4 | 47 | 1500 | 150 | 60 | 71/148 |
| PT-47/1500-30 | 3.0 | 47 | 1500 | 180 | 60 | 57/120 |
| PT-58/1800-12 | 1.99 | 58 | 1800 | 110 | 60 | 123/258 |
| PT-58/1800-18 | 2.66 | 58 | 1800 | 150 | 60 | 85/172 |
| PT-58/1800-20 | 2.98 | 58 | 1800 | 175 | 60 | 73/155 |
| PT-58/1800-24 | 3.56 | 58 | 1800 | 220 | 60 | 56/118 |
| PT-58/1800-30 | 4.43 | 58 | 1800 | 260 | 60 | 45/96 |
Advantage:
Vacuum tube solar energy work principle is the use of heat absorbing coating on the inner tube of the solar light absorption and heat inside the tube in the water in the water tank or even box to improve the water temperature.
As a set of hot plate, it is also carried out in the heat of the heat transfer in the same time, only three ways of radiation conduction convection.
Vacuum tube solar energy heat transfer three kinds of heat transfer is very small tube of the mercury coating to prevent heat radiation and heat conduction in the middle of the vacuum layer to prevent heat conduction as the heat of the convection heat transfer to the vacuum tube solar energy is almost zero.
The thermal efficiency of 93.5% is higher than that of flat panel solar energy increased by 50-80%.
Packaging & Delivery
Packaging Details:
1. Standard export packing for FCL order.
2. Special packing for LCL order.
Delivery Detail:
10-15 days after receipt of deposit
Why choose us?
we have our clients set to list of reasons why to choose us over other solar water heater,here are our benefits
Engaged in the solar energy application technology for more than 18 years
We has received many honors and passed multiple verification.
The number of service outlets across the country, so you have no worry.
We research and produce all kinds of products , widely used in hospitals, schools, hotels, etc.
