Compact Solar Water Heater Flat Plate , Rooftop Solar Hot Water System 150L

Compact Solar Water Heater Flat Plate , Rooftop Solar Hot Water System 150L

    • Compact Solar Water Heater Flat Plate , Rooftop Solar Hot Water System 150L
    • Compact Solar Water Heater Flat Plate , Rooftop Solar Hot Water System 150L
    • Compact Solar Water Heater Flat Plate , Rooftop Solar Hot Water System 150L
    • Compact Solar Water Heater Flat Plate , Rooftop Solar Hot Water System 150L
  • Compact Solar Water Heater Flat Plate , Rooftop Solar Hot Water System 150L

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 150L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Capacity: 150L Structure: Compact
    Loop: Open Loop Collector: Flat Plate
    Outer Tank: Stainless Steel Inner Tank: Stainless Steel 316
    Coating: Blue Titanium Heat Preservation: 72 Hours

    150L Compact Open Loop Flat Plate Thermal Solar Water Heater With High Efficiency Blue Titanium Collector



    Working principle:



    There are two layers water tank, heat transfer fluid circulated between water tank and flat plate collectors naturally. Then it will be heated and transfer energy to water in inner tank.

    Hot water from this kind of solar water heater is pressurized.

    It is easily installed on the house roof.



    Specification:



    Absorber coating: nickel bottom coating + selective black chrome surface.

    Optical performance: absorptive:~94%/emittance:~10%.

    Frame casing: anodized aluminum alloy.

    Cover class: 4mm pattern tempered glass or 4mm low iron tempered patterned glass.

    Insulation: 30-50mm high-density fiberglass board.

    Back sheet: 0.5mm galvanized aluminum plate.

    Sealing profile: EPDM sealing stripe.

    Ext. dimension: 2000×1000×80mm(L×W×H).

    Gross/Aperture Area: 2m²/1.85m².

    Test pressure: 1.6Mpa maximum.



    Product Description

    Technical Description Compact Non-Pressurized Solar Water Heater
    Material of inner tank Food grade SUS 304-2B stainless steel, 0.4mm thickness
    Inner tank diameter Ø360mm
    Material of outer tank Draw bench silver steel (PVDF) with thickness of 0.4mm (Best anti-erode
    material. Especially for the seaside area)
    Outer tank diameter Ø460mm
    Tank insulating layer 50mm high-density polyurethane foam
    Foam pressure 32kg/m3 minimum
    Heat reservation 72 hours
    Material of cap High quality color steel 1.5mm thickness
    Inlet and outlet pipe Male G 3/4" screw, SUS 304-2B stainless steel, 2mm thickness (air vent 1/2'')
    Welding Argon arc welding
    Structure of tank 4 holes: air vent/water inlet /water outlet/back-up hole
    Vacuum tube type 3 target tube AL-N-AL/SS/CU coated
    Material of bracket High quality Aluminum alloy, 1.2-1.4mm thickness
    Structure of bracket Flexibility for flat or slope roof
    Screw for bracket SUS 304 stainless steel 10mm
    Seal High quality silicone rubber polymer
