Flat Plate Solar Powered Water Heater

Flat Plate Solar Powered Water Heater
Flat Plate Solar Powered Water Heater Flat Plate Solar Powered Water Heater Flat Plate Solar Powered Water Heater

Large Image :  Flat Plate Solar Powered Water Heater

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 250L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 5000units/month

Flat Plate Solar Powered Water Heater

Description
Capacity: 250L Circulation: Natural Circulation
Collector: Flat Plate Accessories: P/T Valve, Safety Valve, Magnesium Rod, Electrical Heater, Controller
Outer Tank: Colored Steel Inner Tank: Stainless Steel 304
Bracket: Stainless Steel 304 0/20/30/45 Degrees Heat Preservation: 3 Days
High Light:

non pressurized solar water heater

,

compact solar water heater

Natural Circulation 250L Colored Steel Flat Plate Thermal Solar Water Heater With Clean Water Pollution



Working principle:



There are two layers water tank, heat transfer fluid circulated between water tank and flat plate collectors naturally. Then it will be heated and transfer energy to water in inner tank.

Hot water from this kind of solar water heater is pressurized.

It is easily installed on the house roof.



Advantages:



1. Flat plate collectors with high weather-proof selective absorbing film from full-automatic magnetron sputtering production line developed by Bontel;

2. Flat plate collectors with Bonding heat transferring technology and laser welding technology;

3. Flat plate collectors with high quality low-iron tempered glass with surface treatment to get high transmittance and low emittance;

4. Enamel inner tank with magnesium rod show excellent anticorrosion performance



Feature:



Special design for oversea market: special anodized aluminum alloy frame ensures handsome appearance and can bear high pressure without leakage.

50mm fiberglass insulation and EPDM seal strip to assure the solar collector can work under harsh or very cold temperature.

Operation temperature: -33C~120C.

Patterned tempered glass or low iron tempered glass (4mm thickness) is not broken easily with high transmission and low emission.

Blue/Black chrome coating has absorption rate to ensure excellent efficiency.



Description Of Flat Plate Solar Water Heater



Model No. PT-01 PT-02 PT-03 PT-04
Dimension L×W×T(mm) 2000×1060×70 2000×1000×80 2000×1000×90 2000×1000×100
Gross Area(m2) 2.0 2.0 2.00 2.00
Efficiency Area (m2) 1.82 1.82 1.82 1.82
Gross Weight of Collector(kg) 47±3 55 ±3 47 ±3 55 ±3
Transparent Cover
Number of Cover(pc) 1 1 1 1
Dimension L×W(mm) 1975 × 975 1975 × 975 1975 × 975 1975 × 975
Cover Material Float Glass/Low-iron Glass Float Glass/Low-iron Glass Float Glass/Low-iron Glass Float Glass/Low-iron Glass
Cover Thickness(mm) 4 4 4 4
Cover Transmission 89%-91.4% 89%-91.4% 89%-91.4% 89%-91.4%
Absorber
Dimension L×W(mm) 1840 × 956 1840 × 956 1840 × 956 1840 × 956
Material Red Copper Red Copper Red Copper Red Copper
Surface Treatment Galvanized Chromium Coating Blue Tech Galvanized Chromium Coating Blue Tech
Construction Type Fin and Tube Fin and Tube (Ultrasonic Welding) Fin and Tube Fin and Tube
Header Material T2 Copper tube Copper TP2 T2 Copper tube Copper TP2
Header Tube Size(mm) Ø25 × 1060 × 0.6 2pcs Ø25 × 1060 × 0.6 2pcs Ø25 × 1060 × 0.6 2pcs Ø25 × 1060 × 0.6 2pcs
Rise Material T2 Copper tube Copper TP2 T2 Copper tube Copper TP2
Rise Tube Size(mm) Ø10 × 1886× 0.5 8pcs Ø10 × 1886× 0.5 8pcs Ø10 × 1886× 0.5 8pcs Ø10 × 1886× 0.5 8pcs
Fill Capacity 1.8L Including Header Pipe 1.8L Including Header Pipe 1.6L Including Header Pipe 1.8L Including Header Pipe
