Product Details:
|
| Capacity: | 300L | Working Pressure: | 6 Bar |
|---|---|---|---|
| Collector: | Flat Plate | Testing Pressure: | 10 Bar |
| High ROI(Return On Investment): | 1 To 3 Year Pay Back Time | Flat Panel: | Blue Titanium |
| Outer Tank: | Painted Steel | Inner Tank: | Stainless Steel |
| High Light: | flat panel solar water heater,sun power solar water heater |
||
300L High Efficiency Blue Titanium Stainless Steel Flat Plate Solar Water Heater
Working Principle of Flat Plate Solar Water Heater
Sunlight passes through the glazing and strikes the absorber plate, which heats up, changing solar energy into heat energy. T
he heat is transferred to liquid passing through pipes attached to the absorber plate.
Absorber plates are commonly painted with "selective coatings".
Absorber plates are usually made of copper or aluminum because the metal is a good heat conductor.
Copper is more expensive, but is a better conductor and less prone to corrosion than aluminum.
Special features of compact pressure flat plate solar water heater
1. Suitable to use in all kinds of climates with electric heater
2. Absorbing heat quickly
3. Completely automatic operation
4. It can withstand pressure of tap water when it works
5. Without incrusting, long usage life
6. Multifunction: Bathing, washing, domestic heating
7.Guarantee: Water tank for 2 years, the whole system for 5 years
Advantages Compact Pressurized Flat Plate Solar Water Heater:
Comparing with pressurized heat pipe solar water heater:
1. More simple collector installation;
2. More economical flat plate collector;
3. More strong and safe collector with tempered glass glazing;
4. Traditional solar collector with more market share;
5. Enjoys much more popularity in warm area;
Specifications of Compact Pressure Flat Plate Solar Water Heater
| Flat Plate Solar Collector | Size (mm) | 2000*1060*82 / 2000*1560*82 | |||||
| Cover glass | Low-iron tempered glass with transmittance ≥91% | ||||||
| Coating | Selective black chrome coating with absorptivity ≥95±2% | ||||||
| Absorber | Aluminum strip welded with copper header & riser tubes | ||||||
| Insulation | High-density polyurethane & fiber glass | ||||||
| Frame | Anodized aluminum alloy with anti-aging elastic sealing | ||||||
|
Pressure Water Tank |
Capacity | 100L ~ 300L for pressure hot water storage tank | |||||
| Inner tank | Food-grade stainless steel SUS304-2B / SUS316 / Enamel | ||||||
| Insulation | High-density PU foam with 80~90 hours heat preservation | ||||||
| Tank shell | High-quality stainless steel | ||||||
| Bracket | Shaped strong aluminum alloy, adaptable to flat or slope roof | ||||||
| Accessories | T/P valve, Check valve, Stainless screws | ||||||
|
Auxiliary Equipments
|
Electrical heater, Intelligent controller, Magnesium anode, Pipe & fittings | ||||||
| Collector Angle | 25 ~ 50° | ||||||
| Working Pressure | 6.0 bar | ||||||
| Model Number | Flat Plate Solar Collector |
Aperture Area/ m2 |
Tank Liter |
Container Loading Qty /sets | |||
| Size /mm | Qty /pcs | 20GP | 40GP | 40HQ | |||
| 100 | 2000*1060*82 | 1 | 2 | 100 | 51 | 102 | 124 |
| 120 | 1 | 2 | 120 | 49 | 98 | 119 | |
| 150 | 1 | 2 | 150 | 44 | 89 | 108 | |
| 150 | 2000*1560*82 | 1 | 3 | 150 | 35 | 70 | 85 |
| 200 | 1 | 3 | 200 | 31 | 62 | 75 | |
| 250 | 2000*1060*82 | 2 | 4 | 250 | 25 | 49 | 60 |
| 300 | 2 | 4 | 300 | 23 | 45 | 55 | |
Additional Information
| Payment Terms | T/T, L/C |
| Minimum Order | One 20GP Container |
| Lead Time / Delivery Time | 15 Day(s) |
| Sample Available | YES |
| Delivery Details | One 40HQ within 15 days, ten 40HQ containers within 25 days, otherwise to be noticed |
| FOB Port | Shanghai |
| Packing Info | cartons with foam |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
FAQ
1- What is your Delivery Time?
LCL order/Sample order:10days.
Full container order:14days.
2- What is your Guarantee Time?
5 years.
Provide you with some extra accessories and vacuum tubes, they are free for you.
3- Can you accept OEM ?
YES
4- What is your Payment Term?
We accept T/T or L/C at sight, Western Union.
5-What is your MOQ?
1 sets
6-What is your Packing?
LCL order/Sample order in wood cartoon
Full container order in high quality export carton
7-What is your FOB Port?
We accept FOB Shanghai, Ningbo etc.
8.-What is your Monthly Production Capacity?
6000 sets
9-What is your Shipping Term?
By Sea/Air/Rail
