High Efficient Kitchen Thermal Solar Water Heater System OEM / ODM Available

High Efficient Kitchen Thermal Solar Water Heater System OEM / ODM Available

    • High Efficient Kitchen Thermal Solar Water Heater System OEM / ODM Available
    • High Efficient Kitchen Thermal Solar Water Heater System OEM / ODM Available
    • High Efficient Kitchen Thermal Solar Water Heater System OEM / ODM Available
    • High Efficient Kitchen Thermal Solar Water Heater System OEM / ODM Available
  • High Efficient Kitchen Thermal Solar Water Heater System OEM / ODM Available

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 200L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T, D/P
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Capacity: 200L Outer Tank: Stainless Steel
    Structure: Integrative Principle: Non Pressurized
    Tube: Vacuum Tube Glass Tube: Three Layers, 58 X 1800mm
    Range Of Use: Kitchen Use: Kitchen Heating

    200L Stainless Steel Integrative Non Pressurized Vacuum Tube Thermal Solar Water Heater Kitchen Heating



    Features and advantages



    1. High efficient and economical system.

    2. Especially suitable for projects.

    3. Designed for commercial solar water heating applications.

    4. Reliable and efficient with twin-glass solar tubes.

    5. Polyurethane insulation ensures a good heating performance and minimal heat loss.

    6. Easy plug-in installation.

    7. Can be connected in series to increase water heating capacity.



    Specifications of solar water heater system



    1. Inner tank

    Material: Food grade SUS304-2B stainless steel

    Thickness:0.4mm-0.5mm

    Diameter: Normally 360mm

    2. Outer tank

    Material: SUS201 stainless steel or Painted Steel

    Thickness:0.31mm-0.4mm

    Diameter:Normally 460mm

    3. Insulation layer

    Material:High density polyurethane foam

    Thickness :50-65mm

    Heat preservation :72 hours

    4. Frame

    Material: SUS201 stainless steel or painted steel or aluminum alloy

    Angle:0-45 degree

    5. Optional accessories

    Electric heater, magnesium bar, intelligent controller

    6. Warranty

    Using life of whole system:10 years



    Working Principle:



    1. Non-pressure solar water heater of all glass evacuated tube collector integrated with storage

    tank, are ideal for use in houses and other applications where cheap, reliable hot water supply is required.

    They are simple, economic and practical.
    2. As the specific gravity of hot water and cold water are different, cold water goes downward

    and hot water goes upward.
    3. When cold water in evacuated tubes is heated, it becomes lighter and goes to the water tank,

    while cold water in the tank goes down to the evacuated tubes
    4. Through this circulation, the cold water in the water tank will be gradually heated.



    Convenient install and use:



    ♦ Super anti-erode outer tank:

    outer tank is made by PVDF. Best anti erode material.

    Especially for the seaside area, such as East South Asia and America etc.

    ♦ Feeding water automatic:

    with special design, feeding water automatic and ensure the outlet water as stable temperature.



    Our Service:



    Pre-sale Service

    1. Sample can be offered with sample charge and courier fee by buyer's side.

    2. We have full stock,and can deliver within short time.Many styles for you to choose.

    3. OEM and ODM order are accepted, Any kind of logo printing or design are available.

    4. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.

    5. All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.

    6. We have rich experience of design, manufacture and sell solar water heater, we cherish every order from our honor.



    After you choose

    1. We will count cheapest shipping cost and make invoice to you at once.

    2. Check quality again, then send out to you at 1-2 working day after your payment,

    3. Email you the tracking no, and help to chase the parcels until it arrive you.



    After-sale service

    1. We are very glad that customer give us some suggestion for price and products.

    2. If any question,please contact with us freely by E-mail or Telephone.



    FAQ:



    1. Packing: Standard export carton with foam or wooden box, Wooden Box Packing for Sample

    2. Shipping: 7 days for sample, 15 days for 20/40 container.

    3. MOQ: 20'GP container (Sample is available)

    4. Warranty: 10 years guarantee for whole set solar water heater

    5. Port of departure: Shanghai or Ningbo

    6. Supply ability: 8000 sets per month



    Technical Parameters:



    Vacuum tube Spec.(mm) Φ47×1500 Φ58×1800 Φ70×2000
    Tube (pcs) 12 / 15 / 16 / 18 / 20 / 22/ 24 / 28 / 30 / 36 / 42
    Material 3.3 Borosilicate glass, magnetron spluttering selective coating
    Coating AL/AL-ALN(H)/AL-ALN(L)/ALN or Cu/SS-ALN(H)/SS-ALN(L)/ALN
    Water tank Capacity 70 ~ 400L for inner water tank
    Inner tank Food-grade stainless steel plate SUS304-2B
    Insulation High-density polyurethane integrated foam-forming 50~60mm
    Tank shell Color steel plate
    Bracket Spec.(mm) 1.2 ~ 1.5mm thickness
    Material Hot-dip galvanized steel plate
    Accessories Stainless bolts & nuts, Silicon rubber seal, Dust-proof rubber seal, Plastic pipe holder
    Optional device Electrical heater, Intelligent controller / Assistant tank, Anode magnesium bar
    Tilt angle 25°- 50°
    Water output 45-95°
    Hail resistance Φ25mm diameter
