Non Pressurized Thermal Solar Water Heater Vacuum Tube Enamel White Color

Non Pressurized Thermal Solar Water Heater Vacuum Tube Enamel White Color
Non Pressurized Thermal Solar Water Heater Vacuum Tube Enamel White Color Non Pressurized Thermal Solar Water Heater Vacuum Tube Enamel White Color Non Pressurized Thermal Solar Water Heater Vacuum Tube Enamel White Color Non Pressurized Thermal Solar Water Heater Vacuum Tube Enamel White Color

Large Image :  Non Pressurized Thermal Solar Water Heater Vacuum Tube Enamel White Color

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 300L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T, D/P
Supply Ability: 5000units/month

Non Pressurized Thermal Solar Water Heater Vacuum Tube Enamel White Color

Description
Capacity: 300L Colour: Enamel White
Warranty: 6 Years Accessories: Magnesium Rod, Electrical Heater, Controller
Assistant Tank: 5/8/15L Tube: Vacuum Tube
Principle: Non Pressurized Outer Tank: Stainless Steel
High Light:

non pressurized solar water heater

,

solar hot water heater

,

Enamel White Thermal Solar Water Heater

300L Enamel White Steel Industrial Thermosiphon Non Pressurized Vacuum Tube Thermal Solar Water Heater

How non-pressure solar water heater works?


1. Non-pressure solar water heater of all glass evacuated tube collector integrated with storage tank, are ideal for use in houses and other applications where cheap, reliable hot water supply is required. They are simple, economic and practical.
2. As the specific gravity of hot water and cold water are different, cold water goes downward and hot water goes upward.
3. When cold water in evacuated tubes is heated, it becomes lighter and goes to the water tank, while cold water in the tank goes down to the evacuated tubes
4. Through this circulation, the cold water in the water tank will be gradually heated.



Material:
A) Inner tank: SUS304-2B stainless steel
B) Outer tank: Coated steel sheet
C) Frame: Coated steel sheet



Thickness:
A) Inner tank: 0.4mm
B) Outer tank: 0.4mm
C) Frame: 1.5mm



Heat collector:
All glass vacuum tube 47/1500
All glass vacuum tube 58/1800
A) Coating: Aluminum nitride aluminum (AL-N/AL)
B) Size: 47mm X 1500mm /58mm X 1800mm
C) Heat absorption rate: 88%~93%
D) Qty: 15/20/25/30 pcs



Insulation layer:
A) Material: Imported polyurethane foam (from Bayer Germany)
B) Thickness: 50mm (for maximum 72 hours of conservation)
C) Density: 42kgs / m3



Tank capacity:
A) 90/ 120/ 150/ 180 liters (47/1500)
B) 150 / 200 / 250 / 300 liters (58/1800)
C) Tank diameter: 360 / 410mm



Optional accessories:

Automatic controller/electric heater /magnesium rod/assistant tank

Certificate: CE



6 years international quality warranty for solar water heater, 1 year warranty for automatic controller

Packaging: Vacuum tube / carton (for sample order wooden box packing is required), water tank / carton, frame /carton



Technical Data:



Area (m²) All Glass Vacuum tube

Volume

(L)

GW

(kg)

20GP/40GP/40HQ
loading Qty(sets)
Ø (mm) L (mm) Qty (pcs)
1.87 47 1500 15 90 55 56/118/134
2.60 47 1500 20 120 65 47/102/116
3.25 47 1500 25 150 82 38/74/82
3.75 47 1500 30 180 88 34/70/78
1.97 58 1800 15 150 46 48/100/116
3.70 58 1800 20 200 71 32/68/72
4.75 58 1800 25 250 81 25/52/62
5.60 58 1800 30 300 98 22/46/52





Additional Terms:



Payment Terms L/C, T/T
Minimum Order 2 sets
Lead Time / Delivery Time 15 Day(s)
Sample Available YES
Delivery Details after receipt of payment
Port of Lading Ningbo / Shanghai
Shipping by sea
Packing export carton
Target Market(s) Africa(except Middle East), Central & Southern Asia, Latin America, Southeast Asia
