Bathing Solar Hot Water Tubes Systems , Solar Roof Water Heater Non Pressure

Bathing Solar Hot Water Tubes Systems , Solar Roof Water Heater Non Pressure

    • Bathing Solar Hot Water Tubes Systems , Solar Roof Water Heater Non Pressure
    • Bathing Solar Hot Water Tubes Systems , Solar Roof Water Heater Non Pressure
    • Bathing Solar Hot Water Tubes Systems , Solar Roof Water Heater Non Pressure
    • Bathing Solar Hot Water Tubes Systems , Solar Roof Water Heater Non Pressure
  • Bathing Solar Hot Water Tubes Systems , Solar Roof Water Heater Non Pressure

    Product Details:

    Place of Origin: CHINA
    Brand Name: PASSION/OEM
    Certification: CE
    Model Number: 300L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: CARTONS/PLYWOOD CASE/PALLET
    Delivery Time: 10 working days
    Payment Terms: L/C, T/T, D/P
    Supply Ability: 5000units/month
    Contact Now
    Detailed Product Description
    Capacity: 300L Outer Tank: Colored Steel
    Inner Tank: Stainless Steel 304 2B Structure: Integrated
    Tube: Vacuum Tube Type: Non Pressure
    Range Of Use: Bathing Bracket: Stainless Steel

    300L Colored Steel Integrated Non Pressure Vacuum Tube Solar Water Heater


    . Competitive price and good quality
    . Certification:CE,ISO9001
    . 5-15 years warranty
    . OEM

    How non-pressure solar water heater works?


    1. Non-pressure solar water heater of all glass evacuated tube collector integrated with storage tank, are ideal for use in houses and other applications where cheap, reliable hot water supply is required. They are simple, economic and practical.
    2. As the specific gravity of hot water and cold water are different, cold water goes downward and hot water goes upward.
    3. When cold water in evacuated tubes is heated, it becomes lighter and goes to the water tank, while cold water in the tank goes down to the evacuated tubes
    4. Through this circulation, the cold water in the water tank will be gradually heated.



    Non-pressure solar water heater features:


    1. Cheap and reliable solution, Simple structure, Easy installation
    2. High efficiency
    3. Withstands water pressure no more than 0.1MPa
    4. Operated without any power supplying
    5. Electric heater can be used as back up in rainy days
    6. Hot water can be used directly, or can be used as a preheated



    Solar hot water heating system optional accessories:


    1. Assistant tank: 3/5/8/10/12L
    2. Controller
    3. Electrical heater: 1.5/2/2.5kw



    Solar hot water heating system specification:



    Descripition Non-pressure solar water heater
    Material of out tank wiredrawing steel/ fluorine carbon steel
    Material of inner tank Food grade SUS304 stainless steel
    Tank insulating layer 45kg/m³ high-density polyurethane foamed
    Inlet and outlet hole Male G 1/2, 3/4
    Solar collector tube 3.3 Borosilicate glass with N/Al coating
    Thickness of glass tube 1.6mm
    Vacuum tube tightness P≤0.005 Pa
    Absorption as=0.93-0.96(AM1.5)
    Emission ratio εh=0.04-0.06(80C±5C)
    Idle sunning property parameters Y=220~260m2.C/KW
    Average heat loss coefficient ULT=0.6~0.7W/(m2.C)
    Bracket: 1.5mm thickness galvanized steel
    Structure of tank: 4 holes for air vent,overflow,water inlet and outlet,electric heater
    Welding: Argon arc welding
    Fastening pieces: Made of stainless steel screw



    Capacity

    (Liter)

    Tube specification

    Tube

    quantity

    Packing size

    (CBM)

    Loading quantity(Sets)
            20'GP 40'GP 40'HQ
    100 58mm*1800mm 11 0.432 66 136 160
    135 58mm*1800mm 14 0.540 53 109 128
    150 58mm*1800mm 16 0.648 45 91 106
    165 58mm*1800mm 20 0.720 40 82 96
    200 58mm*1800mm 24 0.864 32 68 80
    250 58mm*1800mm 30 1.080 26 55 64
    300 58mm*1800mm 32 1.152 24 51 60



    Additional Terms:



    Payment Terms L/C, T/T
    Minimum Order 2 sets
    Lead Time / Delivery Time 15 Day(s)
    Sample Available YES
    Delivery Details after receipt of payment
    Port of Lading Ningbo / Shanghai
    Shipping by sea
    Packing export carton
    Target Market(s) Africa(except Middle East), Central & Southern Asia, Latin America, Southeast Asia

    Bathing Solar Hot Water Tubes Systems , Solar Roof Water Heater Non Pressure



    PDF Catalogue of Integrative Non Pressurized Solar Water Heater.

    PT-N Integrative Non Pressurized Solar Water Heate...
