High Efficiency Evacuated Tube Collector Solar Water Heater For Home

High Efficiency Evacuated Tube Collector Solar Water Heater For Home
High Efficiency Evacuated Tube Collector Solar Water Heater For Home  High Efficiency Evacuated Tube Collector Solar Water Heater For Home  High Efficiency Evacuated Tube Collector Solar Water Heater For Home

Large Image :  High Efficiency Evacuated Tube Collector Solar Water Heater For Home

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 200L
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T, D/P
Supply Ability: 5000units/month

High Efficiency Evacuated Tube Collector Solar Water Heater For Home

Description
Capacity: 200L Type: Non Pressurized
Tube: Vacuum Tube Heat Preservation: 3 Days
High ROI(Return On Investment): 1 To 3 Year Pay Back Time Use: Heating Water
Outer Tank: Painted Steel Inner Tank: Stainless Steel 304
High Light:

evacuated tube solar hot water heater

,

solar roof water heater

200L Thermosyphon Non Pressurized Vacuum Tube Solar Water Heater High Efficiency Heating Water



Features:



1. It uses the heat pipe to deliver the heat energy,it can work rapidly;

2. Highly efficient absorber of high performance with daily average efficiency over 50%;

3. Start up quickly, the water is heated rapidly by heat pipe which will transfer the heat energy into the tank;

4. Withstand pressure of 6 bar, more comfortable to use;

5. Simple structure, easy to assembly and install;

6. Can be used all year even in the cold climate area;

7. Long service life, can be used over 15 years.



Working Principle:



This type using all-glasses evacuated tubes as the solar collector for absorbing sun energy and transferring it into heat energy.

As the different densities of hot water and cold water, the hot water flows automatically upwards while the cold water flows down.

The water flowing cycle is created in the tube.

And the water in the storage tank is heated from this natural circulation. The hot water pressure of this non-pressure system is from the gravity.

So it should be installed on the roof or at least 3-4 meters higher than hot water tap.

Or you can install a booster pump to get stronger outlet hot water.



Tehcnical parameters:



Inner tank SUS 304-2B / 1.2mm
Outer tank galvanized steel / 0.35mm
Insulation high density polyurethane foam 50mm
Vacuum tube 58*1800mm ALN/ALN-SS/CU coating
Bracket galvanized steel 1.5mm 0-50 degree
Hail resistance 30mm
Regular capacity 100L, 150L, 200L, 240L, 250L, 300L



Optional Accessories:



1. Booster Pump (adding the hot water out pressure)

2. Temperature Monitor(showing hot water temperature inside the main tank)

3. Electrical Heater (as back-up for cloudy or rainy day)



MODEL: Solar Vacuum Tube Absorber Area Aperture Area Capacity Loading Qty/sets
Item No. Qty /(pcs) Size/(mm) (m2) (m2) (L) 20GP/40HQ
58/1800/10 10 Φ58 X 1800 0.80 0.930 100 80/191
58/1800/12 12 Φ58 X 1800 0.96 1.116 120 67/159
58/1800/15 15 Φ58 X 1800 1.20 1.390 150 54/127
58/1800/16 16 Φ58 X 1800 1.28 1.488 160 50/119
58/1800/18 18 Φ58 X 1800 1.44 1.674 180 45/106
58/1800/20 20 Φ58 X 1800 1.60 1.860 200 39/98
58/1800/22 22 Φ58 X 1800 1.76 2.046 220 37/87
58/1800/24 24 Φ58 X 1800 1.92 2.232 240 33/80
58/1800/25 25 Φ58 X 1800 2.00 2.325 250 32/76
58/1800/30 30 Φ58 X 1800 2.40 2.790 300 27/64
58/1800/36 36 Φ58 X 1800 2.88 3.348 360 22/53
58/1800/40 40 Φ58 X 1800 3.20 3.720 400 20/48
58/1800/42 42 Φ58 X 1800 3.36 3.906 420 19/46
58/1800/48 48 Φ58 X 1800 3.84 4.464 480 17/40



Additional Terms:



Payment Terms L/C, T/T
Minimum Order 2 sets
Lead Time / Delivery Time 15 Day(s)
Sample Available YES
Delivery Details after receipt of payment
Port of Lading Ningbo / Shanghai
Shipping by sea
Packing export carton
Target Market(s) Africa(except Middle East), Central & Southern Asia, Latin America, Southeast Asia
