Aluminum Foil Insulation Solar Pipe Insulated Solar Hose For Solar Water Heater

Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater
Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater

Large Image :  Aluminum Foil Insulation Solar Pipe Insulated Solar Hose For Solar Water Heater

Product Details:
Place of Origin: China
Brand Name: OEM
Certification: CE
Model Number: 5/10/15/25mm
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD1/M
Packaging Details: Cartons
Delivery Time: 5 days
Supply Ability: 1000units/day

Aluminum Foil Insulation Solar Pipe Insulated Solar Hose For Solar Water Heater

Description
Pipe Material: Flexible MOQ: 100M
Dimension: 1/2",3/4",1",1.25"1.5" Insulation Material: Aluminum Foil Insulation
Jacketing Protection: Seamless ,uv-resistance,PE-HD Sensor Cable: Silicon 2-core
Package: Cartons Application: Solar Water Heater Accessories
High Light:

solar water heater spare parts

,

hot water heater accessories

Aluminum Foil Insulation Solar Pipe Insulated Solar Hose for Solar Water Heater



Introduction:
Our
Aluminum Foil Insulation Solar Pipe is specially designed for solar thermal applications.

It is used to connect with solar collectors and storage tanks in a professional way, and making it compatible with modern constructions.



The stainless steel corrugated pipe allows the connection from the collector to the pump unit without any joints.

Some of the pipe left from the pump unit can be connected to the tank directly using extra fittings.



Model Number Size SS Pipe Wall Thickness(mm) Roll Lengths(m)
PT-12-13/20 DN12(1/2”) 316L 13/20 10,15,20,25,30,50
PT-16-13/20 DN16(3/4”) 316L 13/20 10,15,20,25,30,50
PT-20-13/20 DN20(1”) 316L 13/20 10,15,20,25,30,50
PT-12-13/20 DN12(1/2”) SUS304 13/20 10,15,20,25,30,50
PT-16-13/20 DN16(3/4”) SUS304 13/20 10,15,20,25,30,50
PT-20-13/20 DN20(1”) SUS304 13/20

10,15,20,25,30,50




Introduction



pre insulated flexible solar hose only require 1 step to finish the Solar Water Heater Pipe Installation.



Aluminum Foil Insulation Solar Pipe with 304 stainless steel Solar Hose.

It is an ideal choice for your solar thermal system.



It realizes the fast pipe connection among solar collectors, the pump station and the water tank. Non-welding required.



The system is light weight and space saving, which is easy to handle, even in confined spaces.

Flow and return pipes are marked clearly and can be easily distinguished.



Smart Design- Break Point does good to installer separate twin pipes into 2 pipes without any destroy of the jacket protection, meeting the installation demand very well.



Application



Piping systems for solar hot water, heating, heat pumps and air conditioning technology indoor, outdoor or underground piping system.



Coil length is available in 10, 15,20,30,60 meters.

Other length is available upon customer's request

Save money. Easy connection, no soldering required, Saves installation time, reduction costs.



Save time, Save space ,Save labor cost, Realize the fast , easy and reliable solar pipes installation

Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater 0Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater 1Aluminum Foil Insulation Solar Pipe Insulated  Solar Hose For Solar Water Heater 2
