Multi Function Vacuum Tube Solar Collector 304 Stainless Steel Double Side Manifold

Multi Function Vacuum Tube Solar Collector 304 Stainless Steel Double Side Manifold
Multi Function Vacuum Tube Solar Collector 304 Stainless Steel Double Side Manifold Multi Function Vacuum Tube Solar Collector 304 Stainless Steel Double Side Manifold Multi Function Vacuum Tube Solar Collector 304 Stainless Steel Double Side Manifold

Large Image :  Multi Function Vacuum Tube Solar Collector 304 Stainless Steel Double Side Manifold

Product Details:
Place of Origin: CHINA
Brand Name: PASSION/OEM
Certification: CE
Model Number: 50 Tubes
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CARTONS/PLYWOOD CASE/PALLET
Delivery Time: 10 working days
Payment Terms: L/C, T/T, D/P
Supply Ability: 5000units/month

Multi Function Vacuum Tube Solar Collector 304 Stainless Steel Double Side Manifold

Description
Model: 50 Tubes Collector: Double Side
Warranty: 6 Years Using: Project
Manifold: Stainless Steel Inner Tank: Stainless Steel
Bracket: Stainless Steel Heat Preservation: 72 Hours
High Light:

vacuum tube hot water solar collector

,

solar evacuated tube collectors



Multi Function Vacuum Tube Solar Collector 304 Stainless Steel Double Side Manifold



Features



1. Applicable to solar hot water supply / swimming pool heating / house heating.
2. Operates automatically,telecommuting controlling.

3. All-day/time-lapse mode
4. The design allows for versatile architectonic integration.
5. Any type of back up heating can be combined.



Vacuum tube Size (mm) Φ47×1500 / Φ58×1800
Tube (pcs) 20/30/40/50 / 60
Material Borosilicate glass, magnetron spluttering coating
Coating AL/AL-ALN(H)/AL-ALN(L)/ALN or Cu/SS-ALN(H)/SS-ALN(L)/ALN
Manifold Dimension 180*160mm, 1” male thread inlet & outlet
Inner tank Food-grade SUS304-2B stainless steel
Tank shell Stainless steel SUS304-BA / SUS304-2B
Insulation Imported polyurethane integrated foam-forming
Bracket Stainless square tube steel
Accessories Stainless bolts & nuts, waterproof silicon rubber seal,
dustproof rubber seal, plastic pipe holder
Tilt angle 0°~ 90°
Hail resistance Φ25mm diameter



Solar Collector Key Features


· absorption: >92%
· Emittance: ≤8%
· Daily Efficiency: ≥55%,≥45% in winte
· Max Pressure: 0.6bar
· Anti Freeze: -35°C
· Hail Resistance: 25mm
· Life Time: 15 years



Solar Collector Specification


· Manifold inner Material: 0.4mmStainless steel 304-2B
· Manifold outer Material: 0.8mm Alluminum coating galvanized steel
· Frame Material: 2.0mm Aluminium alloy or stainless steel
· Insulation: 40.0mm Polyturethane Foam, density 38-40 kg/m³
· Vacuum Tube: Borosilicate Glass 3.3 AL-N/SS/CU
· Tube Dimension: φ58mm*1800mm



Usage: For swimming pool heating, sola commercial project hot water supply



Packing and shipping:

MOQ: 20'GP container (Sample is available)

Warranty: 10 years guarantee for whole set solar water heater

Payment term: 30% deposit by TT, Balance for BL by TT or LC

Delivery time: 7 days after confirmed

Port of departure: Shanghai or Ningbo

Supply ability: 8000 sets per month

Package: Standard export cartons



Payment term:

1. T/T 30% Deposit in advance and balance should be paid after receiving the B/L copy.

2. L/C at sight (if your quantity reaches 5*40’ HQ container).

3. Sample order or LCL: we accept western union and one touch business.



Pre-sale Service

1. Sample can be offered with sample charge and courier fee by buyer's side.

2. We have full stock,and can deliver within short time.Many styles for you to choose.

3. OEM and ODM order are accepted, Any kind of logo printing or design are available.

4. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you

5. All of our products are produced by our professional workman and we have our high-work-effect foreign

trade team, you can totally believe our service.

6. We have rich experience of design, manufacture and sell solar water heater, we cherish every order from our honor.



After you choose

1. We will count cheapest shipping cost and make invoice to you at once.

2. Check quality again, then send out to you at 1-2 working day after your payment,

3. Email you the tracking no, and help to chase the parcels until it arrive you.



After-sale service

1. We are very glad that customer give us some suggestion for price and products.

2. If any question,please contact with us freely by E-mail or Telephone.

Multi Function Vacuum Tube Solar Collector 304 Stainless Steel Double Side Manifold 0
